FE Series LED video wall - Direct View LED - digital signage - 1920 x 1080 165" - 36 x 320 x 180 per unit - SMD
| Main Specifications | |
|---|---|
| Product Description | NEC LED-FE019I3-165 FE Series LED video wall - Direct View LED - for digital signage |
| Product Type | LED video wall - Direct View LED |
| Diagonal Size | 165" |
| Commercial Use | Yes - digital signage |
| Number of Screens | 36 |
| Video Wall Configuration | 6x6 |
| Video Wall Resolution | 1920 x 1080 |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 1 ports |
| Connectivity | LAN |
| PC Interface | DVI, 3G-SDI |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Video Wall Display Unit | SMD - 320 x 180 |
| USB | Yes |
| Included Accessories | Overframe kit (6x6), spare parts kit, LED controller, pixel card service tool |
| Power Consumption Operational | 792 Watt |
| Dimensions (WxDxH) - without stand | 144.1 in x 3.1 in x 85 in |
| Weight | 861.56 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED video wall - Direct View LED |
| Power Consumption (Max) | 1368 Watt |
| Power Consumption Operational | 792 Watt |
| Commercial Use | Yes - digital signage |
| Series | FE Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 1 ports |
| PC Interface | DVI, 3G-SDI |
| Modes | Landscape mode |
| Dimensions | Without stand |
| Width | 144.1 in |
| Depth | 3.1 in |
| Height | 85 in |
| Weight | 861.56 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Miscellaneous | |
| Included Accessories | Overframe kit (6x6), spare parts kit, LED controller, pixel card service tool |
| Compliant Standards | FCC Class B certified, RoHS, ETL, IP20, CCC |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% |
| Display | |
| LED Lifetime | 100000 hours |
| Color Support | 281000000000 colors |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate |
| Color Temperature | 3000 - 9500K |
| Image Contrast Ratio | 8000:1 |
| Brightness | 770 cd/m² |
| Viewing Angle | 170° |
| Viewing Angle (Vertical) | 160° |
| Additional Features | 256 Dimming level, 16-bit color processing, 4.0 gamma (max), 2.8 gamma (typical), 1.0 gamma (min) |
| Connections | |
| Connector Type | DVI-D input ¦ HDMI input ¦ LAN ¦ Genlock ¦ 3G-SDI input ¦ RS-232 ¦ USB |
| Dimensions & Weight (Shipping) | |
| Weight (Shipping) | 1457.24 lbs |
| Network & Internet Multimedia | |
| Connectivity | LAN |
| Dimensions & Weight Details | |
| Dimensions & Weight Details | Module - 23.9 in x 1.9 in x 13.5 in x 19.4 lbs |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 1 |
| Video Wall Display Unit | |
| Pixel Pitch | 1.9 mm |
| Pixel Configuration | 3-1 black |
| LED Type | SMD |
| Resolution | 320 x 180 |
| Color Support | 281000000000 colors |
| LED Lifetime | 100000 hours |
| Maintenance | Front |
| Video Wall | |
| Resolution | 1920 x 1080 |
| Diagonal Size | 165" |
| Number of Screens | 36 |
| Configuration | 6x6 |
