Switch - L3 - managed - 32 x 400 Gigabit QSFP56-DD + 128 x 40/100 Gigabit QSFP+ / QSFP28 + 144 x 10 Gigabit / 25 Gigabit / 50 Gigabit SFP+ / SFP28 / SFP56 - front to back airflow - rack-mountable - for P/N: CBL-JNP-SDG4-JPL, CBL-JNP-SDG4-SK, CBL-JNP-SDG4-TW, JNP-3000W-DC-AFO
| Main Specifications | |
|---|---|
| Product Description | Juniper Networks QFX5700E - switch - 32 ports - managed - rack-mountable |
| Device Type | Switch - 32 ports - L3 - managed |
| Enclosure Type | Front to back airflow rack-mountable 5U |
| Ports | 32 x 400 Gigabit QSFP56-DD + 128 x 40/100 Gigabit QSFP+ / QSFP28 + 144 x 10 Gigabit / 25 Gigabit / 50 Gigabit SFP+ / SFP28 / SFP56 |
| Performance | Switching capacity: 25.6 Tbps ¦ Forwarding capacity: 5.3 Bpps |
| Capacity | Packet buffer size: 132 MB ¦ VLAN IDs: 4096 ¦ Link Access Groups (LAGs): 128 |
| MAC Address Table Size | 96K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | BGP, OSPF, OSPFv2, OSPFv3, VRRP, GRE, IGMP, IGMPv2, MLD, PIM-DM, PIM-SM, PIM-SSM |
| Remote Management Protocol | NETCONF, CLI, OVSDB, DHCP, MLD, SSH, SSH-2, SNMP 1, SNMP 2, SNMP 3, IPv4, IPv6 |
| Features | Modular design, hot swap fan tray, EVPN, VXLAN, DCI, ZTP, JET, JTI, DCBX support, PFC, congestion management, multicast mode, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), BPDU protection, loop protection, root protection, VSTP, VLAN trunking, RVI, port-based VLAN, MAC Learning Disable, LACP, LLDP, FBF, IPv4 support, IPv6 support, LFA, BGP, IS-IS, IGMP snooping, IGMP snooping v2, IGMP snooping v3, IGMP proxy, MLD snooping, DoS protection, image rollback, Storm Control, LLQ, WRED, ECN, RoCE v2, BFD, SPAN, RSPAN, ERSPAN, sFlow v5 |
| Compliant Standards | IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1ab (LLDP), IEEE 802.1p, Shaped Deficit Weighted Round-Robin (SDWRR), IEEE 802.1ad, IEEE 802.3x, IEEE 802.1Qbb, IEEE 802.1Qaz |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 19 in x 32.1 in x 8.7 in |
| Weight | 153.88 lbs |
| Manufacturer Warranty | 1-year warranty |
| Designed For | P/N: CBL-JNP-SDG4-JPL, CBL-JNP-SDG4-SK, CBL-JNP-SDG4-TW, CBL-JNP-SDG4-US-L6, CBL-JNP-SDG4-US-L7, JNP-3000W-AC-AFO, JNP-3000W-DC-AFO, JNP5700-FAN, JNP5K-RMK-4POST |
| General | |
| Device Type | Switch - 32 ports - L3 - managed |
| Enclosure Type | Front to back airflow rack-mountable 5U |
| Ports | 32 x 400 Gigabit QSFP56-DD + 128 x 40/100 Gigabit QSFP+ / QSFP28 + 144 x 10 Gigabit / 25 Gigabit / 50 Gigabit SFP+ / SFP28 / SFP56 |
| Performance | Switching capacity: 25.6 Tbps ¦ Forwarding capacity: 5.3 Bpps |
| Capacity | Packet buffer size: 132 MB ¦ VLAN IDs: 4096 ¦ Link Access Groups (LAGs): 128 |
| MAC Address Table Size | 96K entries |
| Jumbo Frame Support | 9216 bytes |
| Routing Protocol | BGP, OSPF, OSPFv2, OSPFv3, VRRP, GRE, IGMP, IGMPv2, MLD, PIM-DM, PIM-SM, PIM-SSM |
| Remote Management Protocol | NETCONF, CLI, OVSDB, DHCP, MLD, SSH, SSH-2, SNMP 1, SNMP 2, SNMP 3, IPv4, IPv6 |
| Authentication Method | RADIUS, TACACS+ |
| Features | Modular design, hot swap fan tray, EVPN, VXLAN, DCI, ZTP, JET, JTI, DCBX support, PFC, congestion management, multicast mode, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), BPDU protection, loop protection, root protection, VSTP, VLAN trunking, RVI, port-based VLAN, MAC Learning Disable, LACP, LLDP, FBF, IPv4 support, IPv6 support, LFA, BGP, IS-IS, IGMP snooping, IGMP snooping v2, IGMP snooping v3, IGMP proxy, MLD snooping, DoS protection, image rollback, Storm Control, LLQ, WRED, ECN, RoCE v2, BFD, SPAN, RSPAN, ERSPAN, sFlow v5 |
| Compliant Standards | IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.1Q, IEEE 802.3ad (LACP), IEEE 802.1ab (LLDP), IEEE 802.1p, Shaped Deficit Weighted Round-Robin (SDWRR), IEEE 802.1ad, IEEE 802.3x, IEEE 802.1Qbb, IEEE 802.1Qaz |
| Processor | 1 x Intel |
| RAM | 32 GB |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Compliant Standards | Plug and Play, CAN/CSA-C22.2 No. 60950-1, UL 60950-1, EN 60950-1, IEC 60950-1, EN 60825-1, UL 62368-1 Second Edition, IEC 62328-1 Second Edition, UL 62328-1 Second Edition, FCC CFR47 Part 15, ICES-003, ICES-GEN, EN 55032, EN 55035, EN 300 386 V1.6.1, EN 300 386 V2.1.1, CISPR 32, CISPR 35, IEC/EN 61000, AS/NZS CISPR 32, VCCI, BSMI CNS 15936, KS C 9835, KS C 9832, KS C 9610, RoHS, REACH, WEEE |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 2 |
| Max Supported Qty | 4 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | N+N |
| Power Provided | 3000 Watt |
| 80 PLUS Certification | 80 PLUS Silver |
| Software / System Requirements | |
| Software Included | Junos OS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 158 °F |
| Humidity Range Storage | 5 - 95% (non-condensing) |
| Dimensions & Weight | |
| Width | 19 in |
| Depth | 32.1 in |
| Height | 8.7 in |
| Weight | 153.88 lbs |
| Compatibility Information | |
| Designed For | P/N: CBL-JNP-SDG4-JPL, CBL-JNP-SDG4-SK, CBL-JNP-SDG4-TW, CBL-JNP-SDG4-US-L6, CBL-JNP-SDG4-US-L7, JNP-3000W-AC-AFO, JNP-3000W-DC-AFO, JNP5700-FAN, JNP5K-RMK-4POST |
