LED video wall - education / business - Android - 1920 x 1080 163" - 144 x - 3-in-1 SMD - HDR
| Main Specifications | |
|---|---|
| Product Description | Hisense All-in-one HAIO163DE LED video wall - for education / business |
| Product Type | LED video wall |
| Diagonal Size | 163" |
| Commercial Use | Yes - education / business |
| Number of Screens | 144 |
| Video Wall Configuration | 24x6 |
| Platform | Android |
| Video Wall Resolution | 1920 x 1080 |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate, 7680 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Connectivity | Wi-Fi, Bluetooth, LAN |
| PC Interface | USB-C |
| LCD Backlight Technology | LED backlight AI Precision Dimming |
| TV Tuner | No tuner |
| Commercial Features | Curved installation supported, Open Pluggable Standard (OPS) support |
| Picture Enhancements | MEMC, Ultimate Motion, Bright Color Balance Technology |
| Speaker System | 6 speakers |
| Video Wall Display Unit | 3-in-1 SMD - die-casting aluminum |
| Storage Capacity | 64 GB |
| USB | 2 ports |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 720 Watt |
| Dimensions (WxDxH) - display unit | 5.9 in 13.3 in |
| General | |
| Product Type | LED video wall |
| Power Consumption (Max) | 2100 Watt |
| Power Consumption Operational | 720 Watt |
| Commercial Use | Yes - education / business |
| Platform | Android |
| Operating System | Android OS 9.0 |
| HDR Capable | Yes |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| PC Interface | USB-C |
| Picture Enhancements | MEMC, Ultimate Motion, Bright Color Balance Technology |
| Design | Simple Precise Design |
| Dimensions | Display unit |
| Width | 5.9 in |
| Height | 13.3 in |
| Miscellaneous | |
| Compliant Standards | CB, FCC, cTUVus |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% RH |
| Display | |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate, 7680 Hz Refresh Rate |
| LCD Backlight Technology | LED backlight AI Precision Dimming |
| Color Temperature | 2000 - 9300K |
| Image Contrast Ratio | 5000:1 |
| Brightness | 500 cd/m² |
| Viewing Angle | 150° |
| Viewing Angle (Vertical) | 140° |
| Display Menu Language | Chinese, English, French, German, Spanish, Italian, Polish, Arabic |
| Commercial Features | Curved installation supported, Open Pluggable Standard (OPS) support |
| Additional Features | 14-bit Processing, 95% brightness uniformity, Automatic PQ Adjustment, Super Energy Saving, Smart Calibration, Smart Detection |
| Connections | |
| Connector Type | 3 x HDMI ¦ USB 2.0 ¦ USB-C 3.0 ¦ Audio output ¦ RS-232 ¦ LAN ¦ SPDIF output |
| Audio System | |
| Digital Audio Format | Dolby Audio, DTS digital output |
| Speaker System | 6 speakers |
| Output Power / Total | 60 Watt |
| Additional Features | Hi-Fi Audio |
| Speakers | 6 x speaker - 10 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 100.4 in |
| Depth (Shipping) | 7.6 in |
| Height (Shipping) | 40.8 in |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, Bluetooth, LAN |
| LAN Protocol | Ethernet |
| Bluetooth Version | Bluetooth 5.0 |
| Connect & Share | Screen Share, Smart Screen |
| Dimensions & Weight Details | |
| Dimensions & Weight Details | Display unit - 5.9 in 13.3 in ¦ Panel - 141.9 in x 1.3 in x 83.1 in x 357.1 lbs ¦ Cabinet - 23.6 in x 1.3 in x 13.3 in x 8.8 lbs |
| Stands & Mounts | |
| Stand | Optional |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 2 |
| Configuration | ARM Cortex-A73 Quad-Core ( 1.3 GHz ) - 3 GB - 64 GB - Mali-G52 MC1 |
| Video Wall Display Unit | |
| Pixel Pitch | 1.875 mm |
| Pixel Density | 284444 pixels/m² |
| LED Type | 3-in-1 SMD |
| Aspect Ratio | 16:9 |
| LED Lifetime | 100000 hours |
| Maintenance | Front |
| Cabinet Frame Material | Die-casting aluminum |
| Video Wall | |
| Resolution | 1920 x 1080 |
| Diagonal Size | 163" |
| Number of Screens | 144 |
| Configuration | 24x6 |
