Network adapter - PCIe 3.0 x8 low profile - 10 Gigabit SFP+ x 4
| Main Specifications | |
|---|---|
| Product Description | Axiom - network adapter - PCIe 3.0 x8 - 10 Gigabit SFP+ x 4 |
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 3.0 x8 |
| PCI Specification Revision | PCIe 3.0 |
| Ports | 10 Gigabit SFP+ x 4 |
| Dimensions (WxDxH) | 5.5 in x 4.7 in |
| Weight | 4.97 oz |
| Data Link Protocol | 10GbE, 1GbE |
| Processor | Intel X710-BM2 |
| System Requirements | FreeBSD 10, FreeBSD 9, Linux Kernel 2.6.32 - 3.x, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 6.5, Red Hat Enterprise Linux 7, SUSE Linux Enterprise Desktop 11 SP3, SuSE Linux Enterprise Server 12, VMware ESXi 5.1, VMware ESXi 5.5 |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 3.0 x8 |
| PCI Specification Revision | PCIe 3.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Low-profile bracket |
| Networking | |
| Ports | 10 Gigabit SFP+ x 4 |
| Connectivity Technology | Wired |
| Data Link Protocol | 10 Gigabit Ethernet, Gigabit Ethernet |
| Remote Management Protocol | SNMP, RMON |
| Status Indicators | Link, activity |
| Features | iSCSI boot, PXE boot, WDT, VXLAN, NVGRE, NAS support |
| Software / System Requirements | |
| OS Required | FreeBSD 10, FreeBSD 9, Linux Kernel 2.6.32 - 3.x, Microsoft Windows Server 2008, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Red Hat Enterprise Linux 6.5, Red Hat Enterprise Linux 7, SUSE Linux Enterprise Desktop 11 SP3, SuSE Linux Enterprise Server 12, VMware ESXi 5.1, VMware ESXi 5.5 |
| Processor / Memory | |
| Processor | Intel X710-BM2 |
| Dimensions & Weight | |
| Depth | 5.5 in |
| Height | 4.7 in |
| Weight | 4.97 oz |
