Power distribution unit (rack-mountable) - AC 208 V - 7.3 kW - USB, Ethernet 10/100/1000 - input: IEC 60320 C20 - output connectors: 36 (18 x IEC 60320 C13, 18 x IEC 60320 Cx)
| Main Specifications | |
|---|---|
| Product Description | Server Technology PRO3X Switched PDU C3W36RL-0AJE2NT4 - power distribution unit - 7.3 kW |
| Device Type | Power distribution unit - rack-mountable |
| Input Voltage | AC 208 V |
| Output Voltage | AC 208 V |
| Power Capacity | 7.3 kW |
| Input Connectors | 1 x power IEC 60320 C20 |
| Output connectors | 18 x power IEC 60320 C13 12 A ¦ 18 x power IEC 60320 Cx 16 A |
| Networking | USB, Ethernet 10/100/1000 |
| Remote Management Protocol | SNMP, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SSH-2, CLI, SFTP, IPv4, IPv6, TACACS+, LDAP, RADIUS |
| Dimensions (WxDxH) | 2.2 in x 2.5 in x 70 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Power distribution unit - rack-mountable |
| Expansion / Connectivity | |
| Interfaces | 2 x management (Gigabit Ethernet) - RJ-45 ¦ 1 x sensor - RJ-45 ¦ 1 x AUX ¦ 1 x console/modem - RJ-45 ¦ 1 x USB - 4 pin USB Type A ¦ 1 x USB - 4 pin USB Type B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 2 years |
| Miscellaneous | |
| Features | LED display, voltage monitoring, current meter, master / slave connections, vertical orientation, email alerts support, active power meter, energy meter, power factor meter, Per Input Power Sensing (PIPS), Per Outlet Power Sensing (POPS), measurement per phase, High Density Outlet Technology (HDOT), apparent power meter, crest factor meter, hot-swappable controller, Branch Current Monitoring, Branch Circuit Protection, environmental sensor ready, simplified load balancing, Ramlock Locking Outlets, Raritan Xerus Technology, Multi Master Linking, 20A trip circuit breakers, 10 kAIC (North America) / (5 kAIC ROW) Interrupt Rating |
| Compliant Standards | UL, EMC, IEC 60950-1, WEEE, UL 489, cTUVus, RoHS 2011/65/EU, EN 55024:2010, TLS v1.2, EN 55032:2012, UL 248, ANSI C12.1, EN 60950-1:2006+A11+A1+A12+A2 |
| Networking | |
| Remote Management Interface | USB, Ethernet 10/100/1000 |
| Remote Management Protocol | SNMP, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, SSH-2, CLI, SFTP, IPv4, IPv6, TACACS+, LDAP, RADIUS |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 8 - 90% (non-condensing) |
| Power Device | |
| Input Voltage | AC 208 V |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power IEC 60320 C20 |
| Power Output Connectors Details | 18 x power IEC 60320 C13 12 A ¦ 18 x power IEC 60320 Cx 16 A |
| Output Voltage | AC 208 V 50/60 Hz |
| Max Electric Current | 20 A |
| Power Capacity | 7.3 kW |
| Circuit Protection | Circuit breaker |
| Dimensions & Weight | |
| Width | 2.2 in |
| Depth | 2.5 in |
| Height | 70 in |
