55" Diagonal Class UM5N-E Series LED-backlit LCD display - digital signage with Integrated Pro:Idiom - webOS - 4K UHD (2160p) 3840 x 2160 - Direct LED - black
| Main Specifications | |
|---|---|
| Product Description | LG 55UM5N-E UM5N-E Series - 55" with Integrated Pro:Idiom LED-backlit LCD display - 4K - for digital signage |
| Product Type | LED-backlit LCD flat panel display with Integrated Pro:Idiom |
| Diagonal Class | 55" |
| Commercial Use | Yes - digital signage |
| Color | Black |
| Platform | webOS |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| Connectivity | Wi-Fi, LAN |
| PC Interface | DisplayPort |
| Technology | IPS |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | Local Key Operation, SNMP support, No Signal image, Crestron Connected Certified, SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign Control compatible, Real Time Communication (webRTC), FailOver, SuperSign WB compatible, LG ConnectedCare, 30-degrees tilting installation, Video Tag, booting logo image, group management, Auto Set ID, SI Server Setting, play via URL, Control Manager, SuperSign Cloud, Mobile CMS, Network Ready, ISM Method, LG Enhanced Kernel Protection (EKP) technology, Promota compatible |
| Settings Cloning Capability | Yes |
| Speaker System | 2 speakers |
| Storage Capacity | 16 GB |
| USB | Yes |
| Included Accessories | Remote control, phone to RS232C gender |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 130 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) - without stand | 48.7 in x 2.3 in x 28 in |
| Weight | 31.31 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display with Integrated Pro:Idiom |
| Power Consumption (Max) | 180 Watt |
| Power Consumption Operational | 130 Watt |
| Diagonal Class | 55" |
| Commercial Use | Yes - digital signage |
| Series | UM5N-E Series |
| Platform | webOS |
| Operating System | webOS 6.0 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Temperature sensor, auto brightness sensor, acceleration sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 3 ports |
| PC Interface | DisplayPort |
| Modes | Portrait mode, landscape mode, Tiling Mode (15 x 15), PM mode |
| Dimensions | Without stand |
| Width | 48.7 in |
| Depth | 2.3 in |
| Height | 28 in |
| Weight | 31.31 lbs |
| Enclosure Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Phone to RS232C gender |
| Compliant Standards | HDCP 2.2, HDCP 1.4, HDCP 1.3, FCC Class B certified, CB, EMC, ERP, NRTL, KC, CEC, Plug and Play, ISO/IEC 15408, Carbon Trust |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Power Consumption (Off Mode) | 0.5 Watt |
| Heat Generation | 444 BTU/h |
| Heat Generation Details | Cabinet - typical - 444 BTU/h ¦ Cabinet - max - 614 BTU/h |
| Features | Smart energy saving, WOL (Wake on LAN) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% |
| Display | |
| LCD Display Technology | IPS |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct LED |
| Coating | Conformal, 28% haze |
| Image Contrast Ratio | 1000:1 |
| Dynamic Contrast Ratio | 1000000:1 |
| Brightness | 500 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Response Time | 8 ms |
| Display Menu Language | Multilingual |
| Backlight Life | 50,000 hour(s) |
| Commercial Features | Local Key Operation, SNMP support, No Signal image, Crestron Connected Certified, SuperSign CMS compatible, SuperSign Control+ compatible, SuperSign Control compatible, Real Time Communication (webRTC), FailOver, SuperSign WB compatible, LG ConnectedCare, 30-degrees tilting installation, Video Tag, booting logo image, group management, Auto Set ID, SI Server Setting, play via URL, Control Manager, SuperSign Cloud, Mobile CMS, Network Ready, ISM Method, LG Enhanced Kernel Protection (EKP) technology, Promota compatible |
| Settings Cloning Capability | Yes |
| Operation Hours / Days | 24 / 7 |
| Additional Features | 1.07 billion colors (8-bit+FRC), Daisy Chain, BEACON technology, picture in picture (no tuner), picture by picture (no tuner), Cisco Certified, cable management |
| Connections | |
| Connector Type | 3 x HDMI input ¦ DisplayPort input ¦ RS-232C input ¦ LAN ¦ IR receiver ¦ USB 2.0 ¦ HDMI output ¦ Audio line-out ¦ RS-232C output |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 Watt |
| Additional Features | Gapless playback |
| Speakers | 2 x speaker - 10 Watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 53.5 in |
| Depth (Shipping) | 6.4 in |
| Height (Shipping) | 31.9 in |
| Weight (Shipping) | 41.67 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi, LAN |
| LAN Protocol | Ethernet |
| Connect & Share | Screen Share |
| Stands & Mounts | |
| Stand | Optional |
| Flat Panel Mount Interface | 300 x 300 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 1 |
| Configuration | 16 GB |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
