Docking station - Thunderbolt 4 - 2 x HDMI, 2 x DP - 1GbE, 2.5GbE - 135 Watt
| Main Specifications | |
|---|---|
| Product Description | j5create - docking station - Thunderbolt 4 - 2 x HDMI, 2 x DP - 1GbE, 2.5GbE |
| Product Type | Docking station |
| Docking Interface | Thunderbolt 4 |
| Video Interfaces | 2 x HDMI, 2 x DP |
| Dimensions (WxDxH) | 7.9 in x 4.3 in x 1.7 in |
| Weight | 24.02 oz |
| Color | Dark, space gray |
| Networking | Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Power | Power adapter 135 Watt Power Provided (DC 20 V) |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Docking station |
| Width | 7.9 in |
| Depth | 4.3 in |
| Height | 1.7 in |
| Weight | 24.02 oz |
| Enclosure Color | Dark, space gray |
| Expansion / Connectivity | |
| Interfaces | 1 x USB-C - 24 pin USB-C ¦ 2 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x network - RJ-45 ¦ 3 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x headphone/microphone combo jack - 3.5mm audio jack ¦ 1 x USB-C Power Delivery 3.0 (98 W) - 24 pin USB-C ¦ 2 x display / video - DisplayPort ¦ 2 x USB 3.2 Gen 1 - 9 pin USB Type A ¦ 1 x USB 2.0 with Fast Charging - 9 pin USB Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Input Device | SD card reader, microSD card reader |
| Cables Included | 1 x Thunderbolt 4 cable - detachable - 2.6 ft |
| Features | Security lock slot (cable lock sold separately), DisplayPort Alt Mode, aluminum housing, up to 40Gbps data transfer, 98W power delivery, slim design |
| Security Slot Type | Kensington security slot |
| Compliant Standards | BC1.2, DisplayPort 1.4, Thunderbolt 4 |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Power | |
| Power Device | Power adapter |
| Power Provided | 135 Watt |
| Voltage Provided | DC 20 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 118.4 °F |
| Video | |
| Max Resolution Details | 8K - 60 Hz (Single Display) ¦ 5120 x 2880 - 60 Hz (Dual Display) ¦ 3840 x 2160 - 60 Hz (Triple Display) ¦ 3840 x 2160 - 60 Hz (Quad Display) |
| System Requirements | |
| OS Required | Apple MacOS, Microsoft Windows |
