Thin client - SFF 1 x Ryzen Embedded R2314 / up to 3.5 GHz - RAM 8 GB - SSD 256 GB - NVMe - Radeon Graphics - Gigabit Ethernet - no OS - monitor: none - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | HP Elite t655 - SFF Ryzen Embedded R2314 2.1 GHz - 8 GB - SSD 256 GB - TAA Compliant |
| Type | Thin client - SFF |
| EU Data Act | Https://compliance-euda.hp.com/ |
| Localization | Language: English / region: United States |
| Processor | 1 x AMD Ryzen Embedded R2314 / 2.1 GHz (up to 3.5 GHz, (Quad-Core) |
| Processor Main Features | 4 Threads |
| Cache Memory | 2 MB L2 cache |
| Cache Per Processor | 2 MB |
| RAM | 8 GB (installed) / 32 GB (max) - DDR4 SDRAM |
| Hard Drive | SSD 256 GB - PCI Express (NVMe) - NVM Express (NVMe) |
| Optical Storage | No optical drive |
| Graphics Controller | AMD Radeon Graphics |
| Networking | 1GbE |
| Power | (50/60 Hz) |
| OS Provided | No operating system |
| Dimensions (WxDxH) | 1.4 in x 7.9 in x 7.9 in |
| Weight | 2.59 lbs |
| TAA Compliant | Yes |
| Environmental Standards | ENERGY STAR Qualified |
| Carbon Footprint | 107.099 kg carbon emissions |
| General | |
| Type | Thin client |
| EU Data Act | Https://compliance-euda.hp.com/ |
| Product Form Factor | SFF |
| Localization | Language: English / region: United States |
| Expansion / Connectivity | |
| Slots | 1 (total) / 0 (free) x M.2 Card (for internal storage) |
| Interfaces | 2 x USB 3.1 Gen 1 (2 front) ¦ 3 x USB-C 3.2 Gen 2 (1 front, 2 rear) ¦ 1 x audio line-out/line-in - mini-jack (1 front) ¦ 3 x DisplayPort 1.2 (3 rear) ¦ 2 x USB 3.2 Gen 1 (2 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 1 x audio line-out/headphones (1 rear) |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| VESA Mounting Interface | 100 x 100 mm, VESA |
| Compliant Standards | EMC, WEEE, EN 60601-1-2, ERP, CECP, RoHS2, SEPA, low halogen, HP GSE |
| TAA Compliant | Yes |
| RAM | |
| Installed Size | 8 GB (installed) / 32 GB (max) |
| Technology | DDR4 SDRAM |
| Effective Memory Speed | 3200 MT/s |
| Rated Memory Speed | 3200 MT/s |
| Form Factor | SO-DIMM 260-pin |
| Slots | 2 (total) / 1 (empty) |
| Configuration Features | 1 x 8 GB |
| Networking | |
| Ethernet Controller | Realtek RTL8111HSH-CG |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Power | |
| Device Type | Power adapter |
| Power Device Name | HP Smart AC Adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Provided | 45 watt |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Cache Memory | |
| Installed Size | L2 cache - 2 MB |
| Cache Per Processor | 2 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | AMD Radeon Graphics |
| Video Interfaces | DisplayPort |
| Max Monitors Supported | 3 |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | SSD |
| Capacity | 1 x 256 GB |
| Interface Type | PCI Express (NVMe) |
| Features | NVM Express (NVMe) |
| Dimensions & Weight | |
| Dimensions & Weight Details | 1.4 in - 7.9 in - 7.9 in - 2.6 lbs - with stand ¦ - 2.5 lbs - without stand |
| Width | 1.4 in |
| Depth | 7.9 in |
| Height | 7.9 in |
| Weight | 2.59 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 4.64 lbs |
| Processor / Chipset | |
| CPU | AMD Ryzen Embedded R2314 |
| Clock Speed | 2.1 GHz |
| Max Turbo Speed | 3.5 GHz |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Upgradability | Not upgradable |
| Processor Main Features | 4 Threads |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| Carbon Footprint | 107.099 kg carbon emissions |
| Manufacturing (kg CO2e) | 57.467 |
| Logistics (kg CO2e) | 0.721 |
| Use (kg CO2e) | 48.269 |
| EOL (kg CO2e) | 0.642 |
