Public LED 5000 Series LED display unit - digital signage 64 x 64 per unit - Direct View LED
| Main Specifications | |
|---|---|
| Product Description | Philips 14HDL5039PM Public LED 5000 Series LED display unit - for digital signage |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Frame Rate & Enhancement Technology | 50 Hz Frame Rate, 60 Hz Frame Rate, 3840 Hz Refresh Rate |
| LCD Backlight Technology | Direct View LED |
| TV Tuner | No tuner |
| Picture Enhancements | Wide Color Gamut |
| Video Wall Display Unit | 64 x 64 - die-casting aluminum |
| Voltage | AC 100-240 V (50/60 Hz) |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Series | Public LED 5000 Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Modes | Landscape mode, portrait mode |
| Picture Enhancements | Wide Color Gamut |
| Design | Bezel Free Design |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Compliant Standards | RoHS, EAC, EN 61000-3-2, EN 61000-3-3, IEC/UL 60950, IEC/UL 62368, IEC 62471, EN 55032, EN 55035, FCC SDOC Part 15 Class A |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Video Wall Power Consumption (Max) | 340 W/m² |
| Video Wall Power Consumption (Typical) | 100 W/m² |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 80% RH |
| Display | |
| Frame Rate & Enhancement Technology | 50 Hz Frame Rate, 60 Hz Frame Rate, 3840 Hz Refresh Rate |
| LCD Backlight Technology | Direct View LED |
| Color Temperature | 4000 - 9500K |
| Image Contrast Ratio | 3000:1 |
| Brightness | 550 cd/m² |
| Viewing Angle | 150° |
| Viewing Angle (Vertical) | 150° |
| Additional Features | 97% brightness uniformity, cable management |
| Video Wall Display Unit | |
| Pixel Pitch | 3.9 mm |
| Pixels Per Panel | 16384 |
| Resolution | 64 x 64 |
| Maintenance | Front |
| Cabinet Frame Material | Die-casting aluminum |
