UPS (rack-mountable / external) - with rail kit - AC 120 V - 900 watt - 1000 VA - 1-phase - lithium ion - USB, RS-232 - output connectors: 6 - 2U - 5 ft cord - black with silver front bezel
| Main Specifications | |
|---|---|
| Product Description | Schneider Electric Easy UPS SRVSL1KRARK - UPS - with rail kit - 900 watt - 1000 VA - Li-Ion |
| Device Type | UPS - rack-mountable / external |
| Cord Length | 5 ft |
| Rack Size | 2U |
| Weight | 28.66 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V |
| Power Capacity | 900 watt / 1000 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 6 x power NEMA 5-15R |
| Battery | Lithium ion |
| Networking | USB, RS-232 |
| Included Accessories | Rail kit, rack mounting brackets, stabilization feet |
| Color | Black with silver front bezel |
| Dimensions (WxDxH) | 17.2 in x 17.8 in x 3.4 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Cord Length | 5 ft |
| Color | Black with silver front bezel |
| Expansion / Connectivity | |
| Interfaces | 1 x management (USB) ¦ 1 x management (RS-232) |
| Expansion Slots | 1 (total) / 1 (free) x Intelligent Slot |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | Rail kit, rack mounting brackets, stabilization feet |
| Cables Included | Serial cable - external ¦ USB cable - external |
| Rack Mounting Kit | Included |
| Features | Horizontal orientation, vertical orientation, rack/tower convertible, internal bypass, LCD display, emergency power off, 3:1 max crest factor, auto-sensing |
| Compliant Standards | TUV, NOM, RETIE, IP20 |
| Networking | |
| Remote Management Interface | USB, RS-232 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% RH (non-condensing) |
| Sound Emission | 50 dBA |
| Battery | |
| Technology | Lithium ion |
| Voltage Provided | 38.4 V |
| Run Time (Up To) | 10 min at full load |
| Recharge Time | 2 hours |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 110 - 120 V |
| Frequency Provided | 50/60 Hz ± 3Hz |
| Input Wiring | 1-phase |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 6 x power NEMA 5-15R |
| Output Voltage | AC 120 V 50/60 Hz |
| Power Capacity | 900 watt / 1000 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 220 joules |
| Efficiency | 90.69% at 100% Load, 80% at 100% Load (150 V), 55% at 60% Load (150 V) |
| Dimensions & Weight | |
| Width | 17.2 in |
| Depth | 17.8 in |
| Height | 3.4 in |
| Weight | 28.66 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 22.8 in |
| Shipping Depth | 21.7 in |
| Shipping Height | 9.4 in |
| Shipping Weight | 40.34 lbs |
