Video/audio splitter - HDMI - over CAT 6 - 8 ports - up to 164 ft
| Main Specifications | |
|---|---|
| Product Description | ATEN VS1828KIT - video/audio splitter - HDMI |
| Device Type | Video/audio splitter |
| Ports Qty | 8 |
| Form Factor | Rack-mountable |
| Data Link Protocol | HDMI |
| Transmission Medium | CAT 6 |
| Max Transfer Distance | 164 ft |
| Dimensions (WxDxH) | 11.6 in x 3.2 in x 0.7 in |
| Weight | 19.75 oz |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Video/audio splitter |
| Form Factor | Rack-mountable |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI (input) - 19 pin HDMI Type A female ¦ 1 x HDMI (output) - 19 pin HDMI Type A female ¦ 8 x link (output) - RJ-45 female ¦ 1 x IR output - mini jack ¦ 1 x management (firmware update) - mini-USB Type B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | 8 x receivers, power cable |
| Cables Included | 1 x IR blaster cable ¦ 8 x IR receiver cable |
| Compliant Standards | EDID compatible, Plug and Play |
| Networking | |
| Ports Qty | 8 |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI |
| Max Resolution | 4096 x 2160 / 3840 x 2160 @ 30 Hz |
| Max Video Bandwidth | 340 MHz |
| Max Transfer Distance | 164 ft |
| Status Indicators | Power, link/activity |
| Features | Power over cable (PoC), 4:4:4 chroma subsampling support, LPCM 7.1 support, Dolby TrueHD support, Dolby Digital Plus support, DTS-HD Master Audio support, EDID changeover switch, 3D support, Deep Color support, 4KV ESD Protector, 8KV ESD Protector, 10.2 Gbps bandwidth, metal housing |
| Compliant Standards | HDCP 1.4 |
| Power | |
| Power Device | External power adapter |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 11.6 in |
| Depth | 3.2 in |
| Height | 0.7 in |
| Weight | 19.75 oz |
