Amplifier - 4 x 75 Watt - black
| Main Specifications | |
|---|---|
| Product Description | Crestron X-Series AMP-X300 - amplifier |
| Product Type | Amplifier |
| Enclosure Color | Black |
| Audio Specifications | Amplifier - 20 - 20000 Hz - 103 dB 0.1% |
| Power | AC 120/230 V (50/60 Hz) |
| Environmental Standards | ENERGY STAR Qualified |
| Dimensions (WxDxH) | 8.7 in x 11 in x 1.7 in |
| Weight | 5.29 lbs |
| General | |
| Product Type | Amplifier |
| Enclosure Color | Black |
| Enclosure Material | Metal |
| Power | |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 75 Watt |
| Power Consumption Idle | 16 Watt |
| Connections | |
| Connectors | 4 x audio line-in (RCA) - rear ¦ 4 x balanced audio input - rear ¦ 4 x speakers output - rear |
| Dimensions & Weight | |
| Width | 8.7 in |
| Depth | 11 in |
| Height | 1.7 in |
| Weight | 5.29 lbs |
| Audio System | |
| Functions | Amplifier |
| Amplifier Class | D |
| Audio Specifications | Amplifier - Response Bandwidth - 20 - 20000 Hz - SNR - 103 dB - THD - 0.1% |
| Output Channel Qty | 4 channels |
| Output Power (per channel) | 75 Watt |
| Amplifier Output Details | 150 Watt - 8 Ohm - 1 channels ¦ 200 Watt - 4 Ohm - 1 channels ¦ 150 Watt - 8 Ohm - 2 channels ¦ 150 Watt - 4 Ohm - 2 channels ¦ 75 Watt - 8 Ohm - 3 channels ¦ 75 Watt - 4 Ohm - 3 channels ¦ 75 Watt - 8 Ohm - 4 channels ¦ 75 Watt - 4 Ohm - 4 channels ¦ 300 Watt - 8 Ohm - 1 channels (bridged) ¦ 150 Watt - 8 Ohm - 2 channels (bridged) ¦ 300 Watt - 1 channels (70V) ¦ 300 Watt - 1 channels (100V) ¦ 150 Watt - 2 channels (70V) ¦ 150 Watt - 2 channels (100V) |
| Features | 70V/100V or 4/8 Ohm operation, rack mountable, bridged output capability |
| Environmental Standards | |
| ENERGY STAR Certified | Yes |
