7000 Series LED-backlit LCD video wall - digital signage - 1920 x 1080 110" - 4 x 55" 240 x 135 (LED unit) / 960 x 540 (cabinet) per unit - 3-in-1 1010 - Direct View LED
| Main Specifications | |
|---|---|
| Product Description | Philips 110HDL7012IA 7000 Series LED-backlit LCD video wall - for digital signage |
| Product Type | LED-backlit LCD video wall |
| Diagonal Size | 110" |
| Commercial Use | Yes - digital signage |
| Number of Screens | 4 |
| Video Wall Configuration | 2x2 |
| Video Wall Resolution | 1920 x 1080 |
| Frame Rate & Enhancement Technology | 50 Hz Frame Rate, 60 Hz Frame Rate, 3840 Hz Refresh Rate |
| Video Interface | HDMI |
| LCD Backlight Technology | Direct View LED |
| TV Tuner | No tuner |
| Video Wall Display Unit | 55" - 3-in-1 1010 - 240 x 135 (LED unit) / 960 x 540 (cabinet) - 8.9 sq.ft - die-casting aluminum |
| Included Accessories | Remote control, 4 power cables (3 m), 2x anti-static gloves, manual suction tool |
| Voltage | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) - display unit | 11.9 in 6.7 in |
| Weight | 0.77 lbs |
| General | |
| Product Type | LED-backlit LCD video wall |
| Commercial Use | Yes - digital signage |
| Series | 7000 Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| Design | Bezel Free Design |
| Dimensions | Display unit |
| Width | 11.9 in |
| Height | 6.7 in |
| Weight | 0.77 lbs |
| Miscellaneous | |
| Included Accessories | 4 power cables (3 m), 2x anti-static gloves, manual suction tool |
| Cables Included | 3 x HDMI cable - 6.6 ft ¦ HDMI cable - 10 ft ¦ USB cable - 10 ft |
| Compliant Standards | ADA |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Video Wall Display Unit Power Consumption (Max) | 310 W |
| Video Wall Display Unit Power Consumption (Typical) | 154.7 W |
| Heat Generation Details | Video wall 635 BTU/m² ¦ Video wall 625 BTU/m² |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 90% RH |
| Display | |
| Frame Rate & Enhancement Technology | 50 Hz Frame Rate, 60 Hz Frame Rate, 3840 Hz Refresh Rate |
| LCD Backlight Technology | Direct View LED |
| Color Temperature | 6500K |
| Image Contrast Ratio | 7000:1 |
| Brightness | 700 cd/m² |
| Viewing Angle | 160° |
| Viewing Angle (Vertical) | 160° |
| Additional Features | 97% brightness uniformity, 16-bit support |
| Connections | |
| Connector Type | HDMI input ¦ IR receiver |
| Remote Control | |
| Type | Remote control |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Battery Included Qty | 2 |
| Battery Required Qty | 2 |
| Dimensions & Weight Details | |
| Dimensions & Weight Details | Display unit - 11.9 in 6.7 in x 0.8 lbs ¦ Cabinet - 47.6 in x 1.1 in x 26.8 in x 41 lbs |
| Stands & Mounts | |
| Flat Panel Mount Interface | 400 x 400 mm |
| VESA Compatibility | Yes |
| Video Wall Display Unit | |
| Pixel Pitch | 1.26 mm |
| Pixel Configuration | 1 red, 1 green, 1 blue |
| Pixels Per Panel | 518400 |
| LED Type | 3-in-1 1010 |
| Resolution | 240 x 135 (LED unit) / 960 x 540 (cabinet) |
| Area | 8.9 sq.ft |
| LED Lifetime | 100000 hours |
| Cabinet Diagonal Size | 55" |
| Cabinet Frame Material | Die-casting aluminum |
| Video Wall | |
| Resolution | 1920 x 1080 |
| Diagonal Size | 110" |
| Number of Screens | 4 |
| Configuration | 2x2 |
