Wireless video/audio extender - up to 66 ft
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series HDMI over Wireless Extender Kit, HDMI Mini Transmitter and HDMI Mini Receiver, 4K 60Hz, 65ft (20M), Wireless HDMI, switchable channel - wireless video/audio extender |
| Device Type | Wireless video/audio extender |
| Form Factor | External |
| Max Transfer Distance | 66 ft |
| Manufacturer Warranty | 1-year warranty |
| Designed For | P/N: DMCS3770L, U280-002-W12, U280-W01-QC3-1, U280-W04-100C2G |
| General | |
| Device Type | Wireless video/audio extender |
| Form Factor | External |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x audio / video (transmitter) - 19 pin HDMI Type A male ¦ 1 x audio / video (receiver) - 19 pin HDMI Type A male |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Cables Included | 2 x USB-A to Micro-USB Type B cable - 3 ft |
| Compliant Standards | Plug and Play, FCC, REACH, RoHS, UKCA, WEEE, IEC 61000-4-2 |
| Networking | |
| Connectivity Technology | Wireless |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Max Transfer Distance | 66 ft |
| Status Indicators | Status |
| Features | 4:4:4 chroma subsampling support, 4:2:2 chroma subsampling support, switch button, ABS housing, ESD Protector |
| Compliant Standards | HDCP 1.4, HDCP 2.2 |
| Power | |
| Power Device | External power adapter (not included) |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 122 °F |
| Humidity Range Operating | 0 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Dimensions (WxDxH) / Weight Details | Transmitter: 1.6 in x 9 in x 0.6 in / 2.1 oz ¦ Receiver: 1.6 in x 9 in x 0.6 in / 1.9 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 5.9 in |
| Shipping Depth | 7.8 in |
| Shipping Height | 3.1 in |
| Shipping Weight | 11.99 oz |
| Compatibility Information | |
| Designed For | P/N: DMCS3770L, U280-002-W12, U280-W01-QC3-1, U280-W04-100C2G |
