ISC Series LED display unit - digital signage 64 x 128 (LED unit) / 128 x 256 (cabinet) per unit
| Main Specifications | |
|---|---|
| Product Description | Samsung IS039C-Y ISC Series LED display unit - for digital signage |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Frame Rate & Enhancement Technology | 3840 Hz Frame Rate |
| TV Tuner | No tuner |
| Commercial Features | Curved installation supported, Y-type cabinet |
| Video Wall Display Unit | 64 x 128 (LED unit) / 128 x 256 (cabinet) - die-casting aluminum |
| Included Accessories | Receiving card, hub boards, SMPS, screws |
| Voltage | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) - display unit | 9.8 in 19.7 in |
| General | |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Series | ISC Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Cooling System | Self cooling |
| Dimensions | Display unit |
| Width | 9.8 in |
| Height | 19.7 in |
| Miscellaneous | |
| Included Accessories | Receiving card, hub boards, SMPS, screws |
| Compliant Standards | IP50, EMC Class A |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Video Wall Display Unit Power Consumption (Max) | 180 W |
| Video Wall Display Unit Power Consumption (Typical) | 54 W |
| Video Wall Power Consumption (Max) | 360 W/m² |
| Video Wall Power Consumption (Typical) | 108 W/m² |
| Heat Generation Details | Cabinet - typical - 92.07 BTU ¦ Cabinet - max - 306.9 BTU |
| Features | Energy save |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 80% |
| Display | |
| Color Support | 281 trillion colors |
| Frame Rate & Enhancement Technology | 3840 Hz Frame Rate |
| Color Temperature | 2800 - 16000K |
| Image Contrast Ratio | 6000:1 |
| Brightness | 2000 cd/m² |
| Viewing Angle | 160° |
| Viewing Angle (Vertical) | 160° |
| Commercial Features | Curved installation supported, Y-type cabinet |
| Additional Features | 16-bit support |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 42.5 in |
| Depth (Shipping) | 22.8 in |
| Height (Shipping) | 26.8 in |
| Weight (Shipping) | 240.74 lbs |
| Dimensions & Weight Details | |
| Dimensions & Weight Details | Display unit - 9.8 in 19.7 in ¦ Cabinet - 19.7 in x 2.5 in x 39.4 in x 26.9 lbs |
| Video Wall Display Unit | |
| Pixel Pitch | 3.9 mm |
| Pixel Density | 65536 pixels/m² |
| Pixels Per Panel | 32768 |
| Resolution | 64 x 128 (LED unit) / 128 x 256 (cabinet) |
| LED Lifetime | 100000 hours |
| Maintenance | Rear and front |
| Modules Configuration (Per Cabinet) | 2x2 |
| Cabinet Frame Material | Die-casting aluminum |
