All-in-one Core i5 10500T / up to 3.8 GHz - RAM 16 GB - SSD 512 GB - UHD Graphics 630 - Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6), Gigabit Ethernet - Win 11 - monitor: LCD 23.8" 1920 x 1080 (Full HD) touchscreen - white
| Main Specifications | |
|---|---|
| Product Description | DT Research Medical Cart Computer 584T - all-in-one Core i5 10500T 2.3 GHz - 16 GB - SSD 512 GB - LCD 23.8" |
| Type | Personal computer - all-in-one |
| Processor | Intel Core i5 (10th Gen) 10500T / 2.3 GHz (up to 3.8 GHz, (6-core) |
| Processor Socket | FCLGA1200 Socket |
| Cache Memory | 12 MB |
| Cache Per Processor | 12 MB |
| RAM | 16 GB (installed) / 64 GB (max) |
| Hard Drive | SSD 512 GB |
| Optical Storage | No optical drive |
| Monitor | 23.8" - LCD - 1920 x 1080 (Full HD) - touchscreen |
| Graphics Controller | Intel UHD Graphics 630 |
| Networking | Bluetooth 5.2, Wi-Fi 6, 802.11a, Wi-Fi 5, 802.11b/g/n, 1GbE |
| OS Provided | Windows 11 |
| Color | White |
| Dimensions (WxDxH) | 22.2 in x 1.6 in x 14.6 in |
| Weight | 14.11 lbs |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | Personal computer |
| Product Form Factor | All-in-one |
| Built-in Devices | RFID/NFC reader, SmartCard reader, speaker, microphone, reading light |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Color | White |
| Expansion / Connectivity | |
| Interfaces | 2 x USB 2.0 ¦ 4 x USB 3.0 ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x headphones - mini-jack ¦ 1 x HDMI ¦ 2 x serial |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| VESA Mounting Interface | 100 x 100 mm |
| Compliant Standards | IP65, IPX2, ANSI/AAMI ES60601-1, IEC 60601-1, IEC 60601-1-2, FCC part 18, FCC Part 15 Class B, GB 17625.1, GB 4943.1, GB/T9254, EMC, RED, RCM, CCC |
| RAM | |
| Installed Size | 16 GB (installed) / 64 GB (max) |
| Networking | |
| Wireless LAN Supported | Yes |
| Data Link Protocol | Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11b, IEEE 802.11g, Ethernet, Gigabit Ethernet, Fast Ethernet |
| Power | |
| Device Type | Power adapter |
| Voltage Required | AC 100-240 V |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Cache Memory | |
| Installed Size | 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | LCD |
| Touchscreen | Yes |
| Diagonal Size | 23.8" |
| Native Resolution | 1920 x 1080 (Full HD) |
| Widescreen Display | Yes |
| Monitor Features | Capacitive touch screen, fanless cooling, antimicrobial coating |
| Graphics Controller | |
| Graphics Processor | Intel UHD Graphics 630 |
| Video Interfaces | HDMI |
| Operating System / Software | |
| OS Provided | Windows 11 |
| Hard Drive | |
| Type | SSD |
| Capacity | 1 x 512 GB |
| Audio Input | |
| Type | Microphone |
| Dimensions & Weight | |
| Width | 22.2 in |
| Depth | 1.6 in |
| Height | 14.6 in |
| Weight | 14.11 lbs |
| Processor / Chipset | |
| CPU | Intel Core i5 (10th Gen) 10500T |
| Clock Speed | 2.3 GHz |
| Max Turbo Speed | 3.8 GHz |
| Number of Cores | 6-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| CPU Socket | FCLGA1200 Socket |
