USB-C, 8K 60 Hz, 240W PD Charging, Black, 1.2 m (4 ft.) - USB cable - 24 pin USB-C (M) to 24 pin USB-C (M) - USB 2.0 / USB 3.0 / USB 3.1 / USB 3.2 / USB4 / Thunderbolt 3 - 48 V - 5 A - 4 ft - 4K60Hz (3840 x 2160) support, 8K60Hz (7680 x 4320) support, USB Power Delivery (240W), up to 40 Gbps data transfer rate, active - black
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series USB4 40Gbps Cable (M/M) - USB-C, 8K 60 Hz, 240W PD Charging, Black, 1.2 m (4 ft.) - USB-C cable - USB-C to USB-C - 1.2 m |
| Type | USB-C cable |
| Features | Active cable, 4K60Hz (3840 x 2160) support, 8K60Hz (7680 x 4320) support, USB Power Delivery (240W), up to 40 Gbps data transfer rate, HDR support, bidirectional, 3D video supported, Chroma subsampling (4:4:4), Chroma subsampling (4:2:2), Chroma subsampling (4:2:0), fast charging support, Display Stream Compression (DSC), 30-bit Deep Color, EDID support, Power Delivery 3.1 (PD 3.1) technology, DisplayPort Alternate Mode 1.4 support, DisplayPort Alternate Mode 2.1 support |
| Cable Length | 1.2 m |
| Connector | 24 pin USB-C - male |
| Connector (Second End) | 24 pin USB-C - male |
| Rated Voltage | 48 V |
| Rated Current | 5 A |
| Compliant Standards | USB 2.0 / USB 3.0 / USB 3.1 / USB 3.2 / USB4 / Thunderbolt 3 |
| Color | Black |
| Package Type | Polybag |
| Manufacturer Warranty | 3-year warranty |
| Designed For | P/N: U280-W01-100C1G, U280-W04-100C2G |
| General | |
| Type | USB-C cable |
| Jacket Material | Thermoplastic elastomer (TPE) |
| American Wire Gauge (AWG) | 34/30/23 |
| Rated Voltage | 48 V |
| Rated Current | 5 A |
| Plated Connector | Gold, nickel |
| Features | Active cable, 4K60Hz (3840 x 2160) support, 8K60Hz (7680 x 4320) support, USB Power Delivery (240W), up to 40 Gbps data transfer rate, HDR support, bidirectional, 3D video supported, Chroma subsampling (4:4:4), Chroma subsampling (4:2:2), Chroma subsampling (4:2:0), fast charging support, Display Stream Compression (DSC), 30-bit Deep Color, EDID support, Power Delivery 3.1 (PD 3.1) technology, DisplayPort Alternate Mode 1.4 support, DisplayPort Alternate Mode 2.1 support |
| Cable Length | 1.2 m |
| Outside Diameter | 0.19 in |
| Color | Black |
| Miscellaneous | |
| Compliant Standards | USB 2.0 / USB 3.0 / USB 3.1 / USB 3.2 / USB4 / Thunderbolt 3, RoHS, USB-IF, WEEE, UL 94, VW-1, FCC Part 15 Class B, UKCA |
| Package Details | Polybag |
| Connectivity | |
| Connector | 24 pin USB-C - male |
| Connector (Second End) | 24 pin USB-C - male |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 7 in |
| Shipping Depth | 0.5 in |
| Shipping Height | 9 in |
| Service & Support | 3-year warranty |
| Compatibility Information | |
| Designed For | P/N: U280-W01-100C1G, U280-W04-100C2G |
