Power adapter - super charger with 6 types of DC - AC 100-240 V - 100 Watt - output connectors: 2 - black
| Main Specifications | |
|---|---|
| Product Description | j5create JUP2290DC - power adapter - super charger with 6 types of DC - 100 Watt |
| Device Type | Power adapter - external |
| Weight | 10.67 oz |
| Input Voltage | AC 100-240 V |
| Output Voltage | 5 / 9 / 12 / 15 / 20 V |
| Power Capacity | 100 Watt |
| Input Connectors | 1 x power Type A |
| Output connectors | 1 x 24 pin USB-C - 20 V 5 A 100 W ¦ 1 x 4 pin USB Type A - 5 V 2.4 A |
| Included Accessories | Power DC jack 5.5 mm (ID: 2.5 mm), power DC jack 4 mm (ID: 1.7 mm), 2 x power DC jack 4.5 mm (ID: 3 mm), power DC jack 5.5 mm (ID: 1.7 mm), power DC jack 11 mm (ID: 4.6 mm) |
| Color | Black |
| Dimensions (WxDxH) | 5 in x 1.3 in x 2.3 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Power adapter - external |
| Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | Power DC jack 5.5 mm (ID: 2.5 mm), power DC jack 4 mm (ID: 1.7 mm), 2 x power DC jack 4.5 mm (ID: 3 mm), power DC jack 5.5 mm (ID: 1.7 mm), power DC jack 11 mm (ID: 4.6 mm) |
| Cables Included | Power cable - detachable ¦ USB-C cable |
| Features | Super Charger, overheat protection, overcharge protection, overcurrent protection, Power Delivery (PD) 3.0, Fast Charge technology |
| Compliant Standards | BSMI, PSB, ETL, PSE Mark, ANSI C63.4-2009, EN 61000-3-3:2008, EN 61000-3-2:2006+A1:2009+A2:2009, CNS13438:2006, RCM, IEC 61000-4-5:2005, IEC 61000-4-6:2008, IEC 61000-4-8:2009, IEC 61000-4-11:2004, EN 55024:2010, IEC 62368-1, EN 55032:2015, IEC 61000-4-3:2010, IEC 61000-4-4:2012, UL 62368-1, EN 55022:2010+AC:2011 Class B, IEC 62368, UL 62368, J3000 (H25), J55032 (H29), IEC 61000-4-2:2008 ED 2.0, FCC Part 15 Subpart B Class B, UKCA, ST-COA, CNS14336-1, BS EN 62368-1:2014+A11, BS EN 55032:2015+A11, BS EN 55035:2017+A11, BS EN 61000-3-3:2013+A1, SAA-203030-EA, IEC62368-1:2014, BS EN IEC 61000-3-2:2019 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Power Device | |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power Type A |
| Power Output Connectors Details | 1 x 24 pin USB-C - 20 V 5 A 100 W ¦ 1 x 4 pin USB Type A - 5 V 2.4 A |
| Output Voltage | 5 / 9 / 12 / 15 / 20 V |
| Max Electric Current | 5 A |
| Power Capacity | 100 Watt |
| Surge Suppression | Yes |
| Dimensions & Weight | |
| Width | 5 in |
| Depth | 1.3 in |
| Height | 2.3 in |
| Weight | 10.67 oz |
