105" Diagonal Class LED-backlit LCD display - digital signage - Android - 5K UHD (2160p) 5120 x 2160 - Direct LED - black
| Main Specifications | |
|---|---|
| Product Description | LG Ultra Stretch 105BM5N-B 105" LED-backlit LCD display - 5K - for digital signage |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 105" |
| Commercial Use | Yes - digital signage |
| Color | Black |
| Platform | Android |
| Resolution | 5120 x 2160 |
| Display Format | 5K UHD (2160p) |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| Connectivity | Wi-Fi (optional), LAN, Bluetooth |
| PC Interface | DisplayPort, USB-C |
| LCD Backlight Technology | Direct LED |
| Image Aspect Ratio | 21:9 |
| TV Tuner | No tuner |
| Commercial Features | LG CreateBoard Share, Local Key Operation, Network Ready, LG ConnectedCare DMS, Display Power Management (DPM), Time Scheduler |
| Picture Enhancements | 72% Color Gamut NTSC |
| Speaker System | 3 speakers |
| Storage Capacity | 64 GB |
| USB | Yes, 10 ports |
| Included Accessories | Remote control, SI07B |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 350 watt |
| Power Consumption Stand by | 0.5 watt |
| Dimensions (WxDxH) - without stand | 98.8 in x 3.7 in x 44.2 in |
| Weight | 198.63 lbs |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption (Max) | 850 watt |
| Power Consumption Operational | 350 watt |
| Diagonal Class | 105" |
| Commercial Use | Yes - digital signage |
| Platform | Android |
| Operating System | Android OS 13 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Auto brightness sensor, proximity sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| PC Interface | DisplayPort, USB-C |
| Modes | Landscape mode |
| Picture Enhancements | 72% Color Gamut NTSC |
| Protection | Tempered glass protection |
| Dimensions | Without stand |
| Width | 98.8 in |
| Depth | 3.7 in |
| Height | 44.2 in |
| Weight | 198.63 lbs |
| Enclosure Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Included Accessories | SI07B |
| Cables Included | HDMI cable |
| Compliant Standards | HDCP 2.3, CB, NRTL, cULus, ERP, FCC Class A certified, EMC, Plug and Play, CEC |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 watt |
| Power Consumption (Off Mode) | 0.5 watt |
| Heat Generation Details | Cabinet - typical - 1194 BTU/h ¦ Cabinet - max - 2900 BTU/h |
| Features | WOL (Wake on LAN) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
| Display | |
| Color Support | 1070000000 colors |
| Resolution | 5120 x 2160 |
| Display Format | 5K UHD (2160p) |
| Image Aspect Ratio | 21:9 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| LCD Backlight Technology | Direct LED |
| Coating | 25% haze |
| Image Contrast Ratio | 4000:1 |
| Dynamic Contrast Ratio | 5000:1 |
| Brightness | 400 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Response Time | 6.5 ms |
| Display Menu Language | Multilingual |
| Backlight Life | 30,000 hour(s) |
| Commercial Features | LG CreateBoard Share, Local Key Operation, Network Ready, LG ConnectedCare DMS, Display Power Management (DPM), Time Scheduler |
| Operation Hours / Days | 16 / 7 |
| Additional Features | 10-bit (8-bit + FRC) |
| Connections | |
| Connector Type | 4 x HDMI input ¦ DisplayPort input ¦ Audio line-in ¦ RS-232C input ¦ LAN input ¦ USB-C with 100W Power Delivery ¦ 4 x USB 3.0 ¦ 3 x USB 2.0 ¦ 3 x USB 2.0 ¦ DisplayPort output ¦ SPDIF output ¦ LAN output |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 3 speakers |
| Output Power / Total | 47 watt |
| Speakers | 2 x speaker - 16 watt ¦ 1 x speaker - 15 watt |
| Dimensions & Weight (Shipping) | |
| Width (Shipping) | 105 in |
| Depth (Shipping) | 11 in |
| Height (Shipping) | 51.4 in |
| Weight (Shipping) | 270.95 lbs |
| Network & Internet Multimedia | |
| Connectivity | Wi-Fi (optional), LAN, Bluetooth |
| LAN Protocol | Gigabit Ethernet |
| Wi-Fi Protocol | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n |
| Bluetooth Version | Bluetooth 5.2 |
| Connect & Share | Screen Share |
| Stands & Mounts | |
| Wall Mount Included | Yes |
| Flat Panel Mount Interface | 1000 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| USB Port | Yes |
| USB Ports Qty | 10 |
| Configuration | ARM Cortex-A76 Quad-Core + ARM Cortex-A55 Quad-Core - 8 GB - 64 GB - Mali-G610 MP4 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
