Label printer - direct thermal / thermal transfer - Roll (6 in) - 300 dpi - up to 300 inch/min - capacity: 1 roll - USB 2.0, USB host, Gigabit LAN
| Main Specifications | |
|---|---|
| Product Description | Toshiba BV410T-TS02-QM-S - label printer - B/W - direct thermal / thermal transfer |
| Printer Type | Label printer - direct thermal / thermal transfer - B/W |
| Weight | 6.61 lbs |
| Max Media Size | Roll (6 in) |
| Min Media Size (Custom) | 1 in |
| Max Media Size (Custom) | 6 in |
| Print Speed | Up to 177.8 ppm - max speed |
| Max Resolution (B&W) | 300 dpi |
| Interface | USB 2.0, USB host, Gigabit LAN |
| RAM Installed (Max) | 128 MB SRAM |
| Flash Memory Installed (Max) | 128 MB |
| Language Simulation | ZPL II, DPL, EPL2, SBPL, TPCL |
| Barcodes | Addendum 2 of 5, Code 128, Code 39, Code 93, EAN/JAN-13, EAN/JAN-8, EAN-128, GS1 DataBar, Industrial 2 of 5, Interleaved 2 of 5, Kix (Netherlands) Post, Matrix 2 of 5, MSI, NEC 2 of 5, NW-7, Postnet, RM4SCC, UPC-A / E, USPS Intelligent Mail, Aztec code, DataMatrix, GS1 DataMatrix, GS1 QR code, MaxiCode, Micro QR code, MicroPDF417, PDF417, QR code, Security QR |
| Media Type | Labels, fanfold paper |
| Fonts | Times Roman, Helvetica, Presentation, Letter Gothic, Prestige Elite, Courier, OCR-A, OCR-B, Gothic 725 Black |
| Features | Transmissive media sensor, reflective media sensor, ribbon end sensor |
| Display Resolution | 5 lines x 21 characters / 128 x 64 |
| Total Media Capacity | 1 roll |
| Networking | Print server |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 7.9 in x 10.5 in x 7.8 in |
| General | |
| Printer Type | Label printer - direct thermal / thermal transfer - monochrome |
| Expansion / Connectivity | |
| Connections | 1 x USB 2.0 ¦ 1 x LAN - RJ-45 ¦ 2 x USB host - 4 pin USB Type A |
| Printer | |
| Print Speed | Up to 177.8 ppm - max speed - 203 dpi |
| Built-in Devices | Status LCD |
| Connectivity Technology | Wired |
| Interface | USB 2.0, USB host, Gigabit LAN |
| Max Resolution (B&W) | 300 dpi |
| Language Simulation | ZPL II, DPL, EPL2, SBPL, TPCL |
| Fonts | Times Roman, Helvetica, Presentation, Letter Gothic, Prestige Elite, Courier, OCR-A, OCR-B, Gothic 725 Black |
| Features | Transmissive media sensor, reflective media sensor, ribbon end sensor |
| Display Resolution | 5 lines x 21 characters / 128 x 64 |
| Barcodes | Addendum 2 of 5, Code 128, Code 39, Code 93, EAN/JAN-13, EAN/JAN-8, EAN-128, GS1 DataBar, Industrial 2 of 5, Interleaved 2 of 5, Kix (Netherlands) Post, Matrix 2 of 5, MSI, NEC 2 of 5, NW-7, Postnet, RM4SCC, UPC-A / E, USPS Intelligent Mail, Aztec code, DataMatrix, GS1 DataMatrix, GS1 QR code, MaxiCode, Micro QR code, MicroPDF417, PDF417, QR code, Security QR |
| RAM | |
| RAM Installed (Max) | 128 MB |
| Technology / Form Factor | SRAM |
| Media Handling | |
| Media Type | Labels, fanfold paper |
| Max Media Size | Roll (6 in) |
| Min Media Size (Custom) | 1 in |
| Max Media Size (Custom) | 6 in |
| Media Sizes | Roll (6 in) |
| Max Printing Width | 4.16 in |
| Max Printing Length | 39.2 in |
| Media Thickness Range | 0.0024 in - 0.012 |
| Roll Maximum Outer Diameter | 5 in |
| Roll Core Diameter | 1 in, 1.5 in, 1.57 in, 42 mm |
| Total Media Capacity | 1 roll |
| Media Feeders | 1 x manual - 1 roll - Roll (6 in) |
| Networking | |
| Networking | Print server |
| Power | |
| Power Device | Power adapter - external |
| Voltage Required | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Power Consumption Operational | 65 watt |
| Power Consumption Stand by | 3.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 25 - 85% RH (non-condensing) |
| Flash Memory | |
| Flash Memory | 128 MB |
| Dimensions & Weight | |
| Width | 7.9 in |
| Depth | 10.5 in |
| Height | 7.8 in |
| Weight | 6.61 lbs |
