55" Diagonal Class (54.64" viewable) - DS Series LED-backlit LCD display - digital signage - Android - 1080p 1920 x 1080 - black
| Main Specifications | |
|---|---|
| Product Description | DynaScan DS552LT5-2 DS Series - 55" Class (54.64" viewable) LED-backlit LCD display - Full HD - for digital signage |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 55" |
| Diagonal Size | 54.64" |
| Commercial Use | Yes - digital signage |
| Color | Black |
| Platform | Android |
| Resolution | 1920 x 1080 |
| Display Format | 1080p |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| Connectivity | LAN |
| PC Interface | HDMI, USB |
| LCD Backlight Technology | LED backlight |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Storage Capacity | 8GB eMMC |
| USB | Yes |
| Included Accessories | Remote control, ambient sensor, IR sensor |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 115 watt |
| Dimensions (WxDxH) | 48.8 in x 3.4 in x 28 in |
| Weight | 61.62 lbs |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption (Max) | 260 watt |
| Power Consumption Operational | 115 watt |
| Diagonal Class | 55" |
| Diagonal Size | 54.64" |
| Commercial Use | Yes - digital signage |
| Series | DS Series |
| Platform | Android |
| Operating System | Android OS 11.0 |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Sensors | Ambient light sensor (ALS), auto orientation sensor |
| Video Interface | HDMI |
| HDMI Ports Qty | 2 ports |
| PC Interface | HDMI, USB |
| Design | 10.7mm bezel, Fanless Design |
| Width | 48.8 in |
| Depth | 3.4 in |
| Height | 28 in |
| Weight | 61.62 lbs |
| Enclosure Color | Black |
| Miscellaneous | |
| Included Accessories | Ambient sensor, IR sensor |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Sleep | 0.5 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 10 - 80% RH (non-condensing) |
| Display | |
| Resolution | 1920 x 1080 |
| Display Format | 1080p |
| Image Aspect Ratio | 16:9 |
| LCD Backlight Technology | LED backlight |
| Image Contrast Ratio | 3000:1 |
| Brightness | 4000 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Response Time | 9 ms |
| Display Menu Language | English |
| Backlight Life | 100,000 hour(s) |
| Additional Features | Carrying handles, Image Retention Protection, Power On/Off Scheduler |
| Connections | |
| Connector Type | 2 x HDMI ¦ RS-232 ¦ LAN ¦ Audio line-out ¦ 2 x USB 2.0 |
| Remote Control | |
| Type | Remote control |
| Battery Included | Yes |
| Network & Internet Multimedia | |
| Connectivity | LAN |
| Wi-Fi Protocol | 802.11a, 802.11ac, 802.11ax, 802.11b, 802.11g, 802.11n |
| Stands & Mounts | |
| Flat Panel Mount Interface | 400 x 400 mm |
| VESA Compatibility | Yes |
| Media Player | |
| Supported Video Formats | H.264, MPEG-1, MPEG-2, MPEG-4, VP9 |
| USB Port | Yes |
| Configuration | ARM Cortex-A53 Quad-Core ( 1.5 GHz ) - 2 GB DDR4 - 8GB eMMC - Mali G52 |
