Battery charger - 63V - AC 120-240 V - 600 Watt - output connectors: 1 - 4 ft cord
| Main Specifications | |
|---|---|
| Product Description | Tycon Solar - battery charger - 63V - 600 Watt |
| Device Type | Battery charger - external |
| Cord Length | 4 ft |
| Weight | 4.3 lbs |
| Input Voltage | AC 120-240 V |
| Output Voltage | DC 63 V |
| Power Capacity | 600 Watt |
| Input Connectors | 1 x power IEC 60320 C14 |
| Output connectors | 1 x hardwire 2-wire |
| Dimensions (WxDxH) | 8.5 in x 4.7 in x 3 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Battery charger - external |
| Cord Length | 4 ft |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Features | Overvoltage protection, overcurrent protection, overload protection, short-circuit protection, LED indicators, MPPT charge controller |
| Compliant Standards | EN 60335-1:2002, EN 60335-2-29:2002 |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 90% |
| Power Device | |
| Input Voltage | AC 120-240 V |
| Frequency Required | 50 - 60 Hz |
| Input Connectors | 1 x power IEC 60320 C14 |
| Power Output Connectors Details | 1 x hardwire 2-wire |
| Output Voltage | DC 63 V |
| Max Electric Current | 9 A |
| Power Capacity | 600 Watt |
| Efficiency | 88% |
| Dimensions & Weight | |
| Width | 8.5 in |
| Depth | 4.7 in |
| Height | 3 in |
| Weight | 4.3 lbs |
