Hard drive array - 20 bays (SATA-600 / SAS-3) - SAS 12Gb/s (external) - rack-mountable - 2U
| Main Specifications | |
|---|---|
| Product Description | Sans Digital RS-Series RS316X12 - hard drive array |
| Device Type | Hard drive array |
| Enclosure Type | Rack-mountable - 2U |
| Max Supported Capacity | 128 TB |
| Interface | SAS 12Gb/s |
| Installed Devices / Modules Qty | 20 (max) |
| Supported Drives | SATA-600 / SAS-3 |
| Storage Controller | RAID (SATA 6Gb/s / SAS 12Gb/s) - RAID JBOD |
| Hard Drive | No HDD |
| Power Redundancy | Yes |
| Dimensions (WxDxH) | 19 in x 25 in x 3.5 in |
| Weight | 33.07 lbs |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Hard drive array |
| Enclosure Type | Rack-mountable - 2U |
| Expansion / Connectivity | |
| Expansion Bays | 20 (total) / 20 (free) x hot-swap - 3.5" |
| Interfaces | 1 x SAS 12Gb/s - 36 pin 4x Shielded Mini MultiLane SAS (SFF-8644) ¦ 2 x SAS (cascading) - 36 pin 4x Shielded Mini MultiLane SAS (SFF-8644) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Features | Built-in 3 cooling fans |
| Cables Included | 1 x mini SAS HD cable |
| Compliant Standards | FCC, UL, RoHS |
| Storage | |
| Max Supported Capacity | 128 TB |
| HDD Array External Interface | SAS 12Gb/s |
| Power | |
| Power Device | Internal power supply |
| Power Redundancy | Yes |
| Power Provided | 500 Watt |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| Data Transfer Rate | 1.2 GBps |
| RAID Level | JBOD |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 19 in |
| Depth | 25 in |
| Height | 3.5 in |
| Weight | 33.07 lbs |
| Chassis | |
| Supported Devices / Modules Qty | 20 |
| Supported Drives | SATA-600 / SAS-3 |
