LSBE Series LED display unit - digital signage 192 x 216 (LED unit) / 384 x 216 (cabinet) per unit - Single SMD - HDR
| Main Specifications | |
|---|---|
| Product Description | LG LSBE015-GD LSBE Series LED display unit - for digital signage |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| HDR Technology | HDR10 Pro |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate |
| Video Interface | HDMI |
| PC Interface | DisplayPort |
| TV Tuner | No tuner |
| Commercial Features | SuperSign CMS compatible, LG ConnectedCare, 90°corner installation supported, CVBA controller |
| Video Wall Display Unit | Single SMD - 192 x 216 (LED unit) / 384 x 216 (cabinet) - 2.2 sq.ft - die-casting aluminum |
| Voltage | AC 100-240 V (50/60 Hz) |
| Dimensions (WxDxH) - display units assembly | 23.6 in x 2.8 in x 13.3 in |
| Weight | 14.33 lbs |
| General | |
| Product Type | LED display unit |
| Commercial Use | Yes - digital signage |
| Series | LSBE Series |
| HDR Capable | Yes |
| HDR Technology | HDR10 Pro |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| PC Interface | DisplayPort |
| Dimensions | Display units assembly |
| Width | 23.6 in |
| Depth | 2.8 in |
| Height | 13.3 in |
| Weight | 14.33 lbs |
| Miscellaneous | |
| Compliant Standards | CB, CCC, FCC, RoHS, cTUVus, REACH, KC, IP50 |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Video Wall Display Unit Power Consumption (Max) | 107 W |
| Video Wall Display Unit Power Consumption (Typical) | 45 W |
| Video Wall Power Consumption (Max) | 530 W/m² |
| Heat Generation Details | Cabinet - max - 365 BTU/h ¦ Cabinet - typical - 153 BTU/h ¦ Cabinet - max - 1808 BTU/m² |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 80% RH |
| Display | |
| Frame Rate & Enhancement Technology | 3840 Hz Refresh Rate |
| Color Temperature | 3200 - 9300K |
| Image Contrast Ratio | 5000:1 |
| Brightness | 600 cd/m² |
| Viewing Angle | 160° |
| Viewing Angle (Vertical) | 150° |
| Commercial Features | SuperSign CMS compatible, LG ConnectedCare, 90°corner installation supported, CVBA controller |
| Additional Features | 14-bit Processing, 97% brightness uniformity |
| Connections | |
| Connector Type | HDMI - on unit controller ¦ DisplayPort - on unit controller ¦ LAN - on unit controller ¦ RS-232C - on unit controller |
| Dimensions & Weight Details | |
| Dimensions & Weight Details | Display units assembly - 23.6 in x 2.8 in x 13.3 in x 14.3 lbs ¦ Display unit - 11.8 in x 0.5 in x 13.3 in x 2.1 lbs ¦ Unit controller - 17.4 in x 2.5 in x 12.1 in x 10.8 lbs |
| Video Wall Display Unit | |
| Pixel Pitch | 1.56 mm |
| Pixel Density | 409600 pixels/m² |
| LED Type | Single SMD |
| Aspect Ratio | 16:9 |
| Resolution | 192 x 216 (LED unit) / 384 x 216 (cabinet) |
| Area | 2.2 sq.ft |
| LED Lifetime | 100000 hours |
| Maintenance | Front |
| Modules Configuration (Per Cabinet) | 2x1 |
| Cabinet Frame Material | Die-casting aluminum |
