Switch - L3 - 48 x 100/1000/2.5G/5G (PoE++) + 2 x 50 Gigabit Ethernet SFP56 + 2 x 25 Gigabit SFP28 (uplink) - rack-mountable - PoE++
| Main Specifications | |
|---|---|
| Product Description | HPE Aruba Networking 6300L 48p Smart Rate 100M/1G/2.5G/5G CL8 2p SFP56 50G 2p SFP28 25G L2 Switch - switch - 48 ports - rack-mountable |
| Device Type | Switch - 48 ports - L3 - stackable |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 5 Gigabit Ethernet |
| Ports | 48 x 100/1000/2.5G/5G (PoE++) + 2 x 50 Gigabit Ethernet SFP56 + 2 x 25 Gigabit SFP28 (uplink) |
| Power Over Ethernet (PoE) | PoE++ |
| Performance | Switching capacity: 780 Gbps ¦ Throughput: 580 Mpps |
| Remote Management Protocol | SNMP 2c, SNMP 3, RMON |
| Features | HPE SmartRate, PoE Class 8, LRM optics support, layer 2 switching, 8MB packet buffer |
| Power Redundancy | Optional |
| Dimensions (WxDxH) | 17.4 in x 15.2 in x 1.7 in |
| General | |
| Device Type | Switch - 48 ports - L3 - stackable |
| Enclosure Type | Rack-mountable 1U |
| Subtype | 5 Gigabit Ethernet |
| Ports | 48 x 100/1000/2.5G/5G (PoE++) + 2 x 50 Gigabit Ethernet SFP56 + 2 x 25 Gigabit SFP28 (uplink) |
| Power Over Ethernet (PoE) | PoE++ |
| Performance | Switching capacity: 780 Gbps ¦ Throughput: 580 Mpps |
| Max Units In A Stack | 10 |
| Remote Management Protocol | SNMP 2c, SNMP 3, RMON |
| Features | HPE SmartRate, PoE Class 8, LRM optics support, layer 2 switching, 8MB packet buffer |
| Processor | 1 x ARM Cortex-A72: 1.8 GHz |
| RAM | 8 GB DDR4 SDRAM |
| Flash Memory | 32 GB |
| Expansion / Connectivity | |
| Interfaces | 48 x 100/1000/2.5G/5G (PoE++) RJ-45 PoE Class 8 ¦ 2 x 50Gbit LAN SFP56 ¦ 2 x 25Gbit LAN SFP28 uplink/stacking ¦ 1 x console RJ-45 out-of-band network management ¦ 1 x management RJ-45 ¦ 1 x USB Type A host |
| Miscellaneous | |
| Included Accessories | 2 fan trays |
| Power | |
| Power Device | Internal power supply - hot-plug |
| Installed Qty | 0 |
| Max Supported Qty | 2 |
| Power Redundancy | Optional |
| Power Redundancy Scheme | 1+1 (with optional power supply) |
| Dimensions & Weight | |
| Width | 17.4 in |
| Depth | 15.2 in |
| Height | 1.7 in |
