Switch - unmanaged - 2 x 10/100/1000/10000 + 2 x 10/100/1000 + 1 x 10GB Ethernet (uplink) - DIN rail mountable - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Omnitron RUGGEDNET 10GMG/Si - switch - 4 ports - unmanaged - TAA Compliant |
| Device Type | Switch - 4 ports - unmanaged |
| Subtype | 10 Gigabit Ethernet |
| Ports | 2 x 10/100/1000/10000 + 2 x 10/100/1000 + 1 x 10GB Ethernet (uplink) |
| Features | Fanless |
| Compliant Standards | IEEE 802.3 |
| Dimensions (WxDxH) | 1.5 in x 5.2 in x 5.5 in |
| Weight | 27.23 oz |
| TAA Compliant | Yes |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Switch - 4 ports - unmanaged |
| Enclosure Type | DIN rail mountable |
| Subtype | 10 Gigabit Ethernet |
| Ports | 2 x 10/100/1000/10000 + 2 x 10/100/1000 + 1 x 10GB Ethernet (uplink) |
| Features | Fanless |
| Compliant Standards | IEEE 802.3 |
| Expansion / Connectivity | |
| Interfaces | 2 x 10Gbit LAN RJ-45 ¦ 2 x 10/100/1000 Base-T ¦ 1 x 10Gbit LAN RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years ¦ Technical support |
| Miscellaneous | |
| MTBF | 239,000 hours |
| Compliant Standards | IP40, REACH, RoHS, WEEE, BAA, NDAA, UL 62368-1, UL 60950-1, IEC 62368-1, IEC 60950-1, EN 62368-1, EN 60950-1, CAN/CSA C22.2 No. 62368-1-14, CAN/CSA C22.2 No. 60950-1, EN 55032/24, IEC 61000-6-4, IEC 61000-6-2, CISPR 32, FCC 47 CFR Part 15 Subpart B Class A, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, UKCA |
| TAA Compliant | Yes |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 167 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Min Storage Temperature | -40 °F |
| Max Storage Temperature | 176 °F |
| Dimensions & Weight | |
| Width | 1.5 in |
| Depth | 5.2 in |
| Height | 5.5 in |
| Weight | 27.23 oz |
