UPS - AC 120 V - 300 Watt - 500 VA - output connectors: 6 - black
| Main Specifications | |
|---|---|
| Product Description | APC Easy UPS BV BV500 - UPS - 300 Watt - 500 VA |
| Device Type | UPS - external |
| Weight | 8.6 lbs |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V |
| Power Capacity | 300 Watt / 500 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 6 x power NEMA 5-15R |
| Battery | Lead acid |
| Color | Black |
| Dimensions (WxDxH) | 6.5 in x 12 in x 3.6 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | UPS - external |
| Color | Black |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | Power cable - external - 5 ft |
| Features | Automatic Voltage Regulation (AVR), LED display |
| Compliant Standards | EAC, EN 62040-1, EN 62040-2, IEC 62040-1, IEC 62040-2, IP20 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 90% |
| Sound Emission | 40 dBA |
| Battery | |
| Technology | Lead acid |
| Transfer Time | 6 ms |
| Power Device | |
| UPS Technology | Line interactive |
| Input Voltage | AC 120 V |
| Input Voltage Range | AC 89 - 145 V |
| Frequency Provided | 50/60 Hz ± 1Hz |
| Frequency Required | 50/60 Hz ± 5Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 6 x power NEMA 5-15R |
| Output Voltage | AC 120 V 50/60 Hz |
| Power Capacity | 300 Watt / 500 VA |
| Output Waveform | Stepped approximation to a sinewave |
| Surge Energy Rating | 156 Joules |
| Dimensions & Weight | |
| Width | 6.5 in |
| Depth | 12 in |
| Height | 3.6 in |
| Weight | 8.6 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 5.6 in |
| Shipping Depth | 14.7 in |
| Shipping Height | 9.3 in |
| Shipping Weight | 9.26 lbs |
