KVM / audio / USB extender - over CAT 5e/6 - 10/100/1000Base-T - up to 328 ft
| Main Specifications | |
|---|---|
| Product Description | ATEN KG6900T - KVM / audio / USB extender |
| Device Type | KVM / audio / USB extender |
| Form Factor | External |
| Cabling Type | 10/100/1000Base-T |
| Transmission Medium | CAT 5e/6 |
| Max Transfer Distance | 328 ft |
| Dimensions (WxDxH) | 2.3 in x 4.8 in x 1 in |
| Weight | 10.58 oz |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | KVM / audio / USB extender |
| Form Factor | External |
| Expansion / Connectivity | |
| Interfaces | 1 x KVM - RJ-45 female ¦ 1 x link - RJ-45 female ¦ 2 x USB - Type A male ¦ 1 x DVI-D male |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10/100/1000Base-T |
| Max Resolution | 1920 x 1200 @ 60 Hz |
| Max Transfer Distance | 328 ft |
| Status Indicators | Link, power, network |
| Features | Aluminum housing, firmware upgradable, bus powered, reset button, HTML5 User Interface support |
| Encryption Algorithm | TLS 1.3, FIPS 140-2 Level 1 |
| Power | |
| Power Consumption Operational | 3.854 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 2.3 in |
| Depth | 4.8 in |
| Height | 1 in |
| Weight | 10.58 oz |
