100GBase-SR4, MTP/MPO MMF, 100 Gbps, 850 nm, 100 m (328 ft.) - QSFP28 transceiver module - 100GbE - 100GBase-SR4 - MTP/MPO-12 multi-mode - up to 328 ft - 840-860 nm
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series Juniper-Compatible JNP-QSFP-100G-SR4 QSFP28 Transceiver - 100GBase-SR4, MTP/MPO MMF, 100 Gbps, 850 nm, 100 m (328 ft.) - QSFP28 transceiver module - 100GbE |
| Device Type | QSFP28 transceiver module - MTP/MPO-12 multi-mode |
| Form Factor | Plug-in module |
| Cabling Type | 100GBase-SR4 |
| Data Transfer Rate | 100 Gbps |
| Optical Wave Length | 840-860 nm |
| Data Link Protocol | 100GbE |
| Max Transfer Distance | 328 ft |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | QSFP28 transceiver module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 100GBase-SR4 - MTP/MPO-12 multi-mode male |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | OM4, MSA, EN 55032, FCC Part 15 C Class B, IEC/EN 63000, RoHS, UKCA |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 100GBase-SR4 |
| Data Link Protocol | 100GbE |
| Data Transfer Rate | 100 Gbps |
| Optical Wave Length | 840-860 nm |
| Max Transfer Distance | 328 ft |
| Features | Digital Diagnostics Monitoring Interface (DDMI), hot swappable, EMI/RFI protection |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 - 85% RH (non-condensing) |
