Travel Laptop Docking Station (117B-USBC-MULTIPORT) - Docking station - USB-C 3.2 Gen 2 / Thunderbolt 3 / Thunderbolt 4 - 2 x HDMI, 2 x DP - 1GbE
| Main Specifications | |
|---|---|
| Product Description | Startech USB-C Triple-Monitor Multiport Adapter, Dual 4K 60Hz + 4k 30Hz HDMI & DisplayPort, 3-Port USB 10Gbps Hub, 100W Power Delivery Pass-Through, GbE, 2ft Cable, Mini Dock - Travel Laptop Docking Station (117B-USBC-MULTIPORT) - docking station - USB-C 3.2 Gen 2 / Thunderbolt 3 / Thunderbolt 4 - 2 x HDMI, 2 x DP - 1GbE |
| Product Type | Docking station |
| Docking Interface | USB-C 3.2 Gen 2 / Thunderbolt 3 / Thunderbolt 4 |
| Video Interfaces | 2 x HDMI, 2 x DP |
| Dimensions (WxDxH) | 2.2 in x 4.8 in x 0.7 in |
| Weight | 3.99 oz |
| Color | Gray |
| Networking | Gigabit Ethernet |
| Power | 15 Watt |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | Docking station |
| Width | 2.2 in |
| Depth | 4.8 in |
| Height | 0.7 in |
| Weight | 3.99 oz |
| Enclosure Color | Gray |
| Expansion / Connectivity | |
| Interfaces | 2 x display / video - HDMI - 19 pin HDMI Type A ¦ 2 x display / video - DisplayPort - 20 pin DisplayPort ¦ 3 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x USB-C with Power Delivery (100 W) - 24 pin USB-C |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | 1 x USB-C 3.2 Gen 2 cable - integrated - 2 ft |
| Features | Wake on LAN, Preboot Execution Environment (PXE) support, full duplex support, bus powered, DisplayPort Alt Mode, plastic housing, triple display support, 100W power delivery (pass-through), up to 10Gbps data transfer, EMI shielding |
| Compliant Standards | FCC, RoHS, WEEE, RCM, DisplayPort 1.4, UASP (USB Attached SCSI Protocol), USB Power Delivery 3.0, DisplayPort 1.2 (Alt Mode) |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Power | |
| Power Consumption (Max) | 15 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Video | |
| Max Resolution Details | 3840 x 2160, 4K (Triple Display) ¦ 3840 x 2160, 4K - 60 Hz (Dual Display) |
| System Requirements | |
| OS Required | Windows 8.1 / 10 / 11, Google Chrome OS 78.x |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 4.9 in |
| Shipping Depth | 9.5 in |
| Shipping Height | 1.3 in |
| Shipping Weight | 7.41 oz |
