Video capture adapter - USB-C 3.2 Gen 1 - black
| Main Specifications | |
|---|---|
| Product Description | j5create JVA01 - video capture adapter - USB-C 3.2 Gen 1 |
| Device Type | Video capture adapter |
| Interface Type | USB-C 3.2 Gen 1 |
| Dimensions (WxDxH) | 2 in x 3.8 in x 0.6 in |
| Weight | 2.43 oz |
| Color | Black |
| Video Input | HDMI input, HDMI output |
| Video Modes | 4K |
| Audio Input Support | Standard |
| Sound Input Mode | - max sample rate: 48 kHz |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Video capture adapter |
| Interface Type | USB-C 3.2 Gen 1 |
| Width | 2 in |
| Depth | 3.8 in |
| Height | 0.6 in |
| Weight | 2.43 oz |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x audio - 3.5mm audio jack ¦ Power - 9 pin USB Type A ¦ 1 x audio / video - HDMI input ¦ 1 x audio / video - HDMI output |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x USB-A cable - external - 1 ft |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 80% (non-condensing) |
| Video | |
| Interface Type | HDMI input, HDMI output |
| Video Modes | 4K |
| Still Image Capture Resolution | 3840 x 2160 |
| Audio Input Support | Standard |
| Audio Sampling Format | Stereo 24-bit / 48 kHz |
| Audio Input | |
| Max Sample Rate | 48 kHz |
