10GBase-SR, LC Duplex MMF, 10 Gbps, 850 nm, 400 m (1312 ft.) - SFP+ transceiver module - 10GbE - 10GBase-SR - LC multi-mode - up to 1310 ft - 840-860 nm
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series Cisco-Compatible SFP-10G-SR SFP+ Transceiver - 10GBase-SR, LC Duplex MMF, 10 Gbps, 850 nm, 400 m (1312 ft.) - SFP+ transceiver module - 10GbE |
| Device Type | SFP+ transceiver module - LC multi-mode |
| Form Factor | Plug-in module |
| Cabling Type | 10GBase-SR |
| Data Transfer Rate | 10 Gbps |
| Optical Wave Length | 840-860 nm |
| Data Link Protocol | 10GbE |
| Max Transfer Distance | 1310 ft |
| Weight | 1.76 oz |
| Manufacturer Warranty | 3-year warranty |
| Designed For | P/N: N820-04M-OM4 |
| General | |
| Device Type | SFP+ transceiver module |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 10GBase-SR - LC multi-mode male x 2 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | OM4, MSA, EN 55032, IEC/EN 63000, RoHS, FCC Part 15 Class B, UKCA |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10GBase-SR |
| Data Link Protocol | 10GbE |
| Data Transfer Rate | 10 Gbps |
| Optical Wave Length | 840-860 nm |
| Max Transfer Distance | 1310 ft |
| Features | Hot swappable, Cisco compatible, EMI/RFI protection, Digital Diagnostics Monitoring (DDM), metal housing, bidirectional |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 158 °F |
| Humidity Range Operating | 5 - 85% RH (non-condensing) |
| Dimensions & Weight | |
| Weight | 1.76 oz |
| Compatibility Information | |
| Designed For | P/N: N820-04M-OM4 |
