Barebone - SFF 1 x Core i5 1340P / up to 4.6 GHz - RAM 0 GB - Intel Iris Xe Graphics - IEEE 802.11ax (Wi-Fi 6E), Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.3
| Main Specifications | |
|---|---|
| Product Description | MSI PRO DP10 13M 022BUS - SFF Core i5 1340P - 0 GB - no HDD |
| Type | PC barebone - SFF |
| Processor | 1 x Intel Core i5 (13th Gen) 1340P (up to 4.6 GHz, (12-core) |
| Cache Memory | 12 MB |
| Cache Per Processor | 12 MB |
| RAM | 0 GB |
| Storage Controller | SATA |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | Intel Iris Xe Graphics |
| Networking | 802.11a, Wi-Fi 5, 802.11b/g/n, Wi-Fi 6E, 1GbE, 2.5GbE, Bluetooth 5.3 |
| OS Provided | No operating system |
| Image Color Disclaimer | The displayed product image may be a different color |
| Dimensions (WxDxH) | 7 in x 1.4 in x 7 in |
| Weight | 2.43 lbs |
| Manufacturer Warranty | Limited warranty - 3 years |
| General | |
| Type | PC barebone |
| Product Form Factor | SFF |
| Built-in Devices | Air cooling solution |
| Embedded Security | Trusted Platform Module (TPM) Security Chip |
| Image Color Disclaimer | The displayed product image may be a different color |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x internal 2.5" |
| Slots | 2 (total) / 2 (free) x M.2 Card |
| Interfaces | 1 x audio line-in/headphones (1 in front) ¦ 5 x USB 3.2 Gen 1 (3 front, 2 rear) ¦ 1 x USB-C 3.2 Gen 2 (1 front) ¦ 1 x HDMI ¦ 1 x Thunderbolt 4 (1 rear) ¦ 1 x LAN (2.5Gigabit Ethernet) (1 rear) ¦ 1 x DisplayPort 1.4 (1 rear) ¦ 1 x VGA (1 rear) ¦ 1 x Wi-Fi antenna (1 rear) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Kensington security slot |
| VESA Mounting Interface | 75 x 75 mm |
| RAM | |
| Installed Size | 0 GB |
| Slots | 2 (total) / 2 (empty) |
| Networking | |
| Ethernet Ports | 2.5 Gigabit Ethernet |
| Ethernet Controller | Realtek RTL8125B-CG |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Data Link Protocol | IEEE 802.11g, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11ax (Wi-Fi 6E), IEEE 802.11b, Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.3 |
| Power | |
| Device Type | Power supply |
| Power Provided | 120 watt |
| Storage Controller | |
| Type | 1 x SATA |
| Cache Memory | |
| Installed Size | 12 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel Iris Xe Graphics |
| Video Interfaces | HDMI, DisplayPort, VGA |
| Operating System / Software | |
| OS Provided | No operating system |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 7 in |
| Depth | 1.4 in |
| Height | 7 in |
| Weight | 2.43 lbs |
| Processor / Chipset | |
| CPU | Intel Core i5 (13th Gen) 1340P |
| Max Turbo Speed | 4.6 GHz |
| Number of Cores | 12-core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
