Network surveillance camera - color (Day&Night) - 2 MP - 1920 x 1080 - 1080p - fixed focal - audio - LAN 10/100 - MJPEG, H.264 - DC 12 V / PoE - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Speco Intensifier IP O2I695 - network surveillance camera - TAA Compliant |
| Device Type | Network surveillance camera - fixed |
| Audio | Yes: two-way audio capability |
| Camera Mount Type | Angle mount |
| Dimensions (WxDxH) | 2.2 in x 2.5 in x 2.8 in |
| Weight | 6.98 oz |
| Color | Stainless steel |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night |
| Max Resolution | 1920 x 1080 |
| Frame Rate (max) | 30 frames per second |
| Motion Detection | Yes |
| Video Modes | 1080p |
| Optical Sensor Type | CMOS - 1/2.8" - 2 MP |
| Minimum Illumination | 0.2 lux - color - F1.4 |
| Focal Length Control | Fixed focal |
| Focal Length | 2.9 mm |
| Lens Iris | F/1.4 |
| Interfaces | Ethernet 10Base-T/100Base-TX |
| Cables Included | 1 - camera cable - 16 ft |
| Voltage | DC 12 V / PoE |
| Features | ONVIF (Profile S) support, Automatic Tracing White (ATW), Automatic Whiteness Balance (AWB), Wide Dynamic Range (WDR), Intensifier technology, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), Constant Bitrate (CBR), Variable Bitrate (VBR), 3 streams capability, 8 users simultaneously, alarm event, digest authentication, email upload, FTP upload, IP address filtering, password protection, Privacy Mask Function, SD Card Backup Recording, Tampering detection |
| TAA Compliant | Yes |
| Manufacturer Warranty | 5-year warranty |
| Environmental Parameters (operating) | 14 °F - 122 °F; 0 - 90% RH relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Audio Support | Yes: two-way audio capability |
| Audio Formats | G.711 |
| Camera Mount Type | Angle mount |
| Connectivity Technology | Wired |
| Width | 2.2 in |
| Depth | 2.5 in |
| Height | 2.8 in |
| Weight | 6.98 oz |
| Expansion / Connectivity | |
| Ports | Microphone ¦ Audio line out ¦ LAN/power |
| Supported Memory Cards | microSD Card |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | Main unit |
| Cables Included | 1 x camera cable - 16 ft |
| TAA Compliant | Yes |
| Compliant Standards | NDAA Section 889 Part B, FCC, RoHS, IEEE 802.3af |
| Color | Stainless steel |
| Power | |
| Power Requirements | DC 12 V / PoE |
| Power Device | 4 watt |
| Software / System Requirements | |
| Software Included | SecureGuard VMS, SecureGuard |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 122 °F |
| Relative Humidity (operating) | 0 - 90% RH |
| Camera | |
| Type | Color - Day&Night - fixed |
| Digital Video Format | MJPEG, H.264 |
| Max Digital Video Resolution | 1920 x 1080 |
| Motion Detection | Yes |
| Video Modes | 1080p |
| Minimum Illumination | 0.2 lux - color - F1.4 |
| Digital Video Capture Resolution | 1920 x 1080 |
| Frame Rate (max) | 30 frames per second |
| Features | ONVIF (Profile S) support, Automatic Tracing White (ATW), Automatic Whiteness Balance (AWB), Wide Dynamic Range (WDR), Intensifier technology, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), Constant Bitrate (CBR), Variable Bitrate (VBR), 3 streams capability, 8 users simultaneously, alarm event, digest authentication, email upload, FTP upload, IP address filtering, password protection, Privacy Mask Function, SD Card Backup Recording, Tampering detection |
| Lens Construction | |
| Type | Fixed focal |
| Focal Length | 2.9 mm |
| Lens Iris | F/1.4 |
| Image Sensor | |
| Type | 2 MP CMOS 1/2.8" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | IPv4, TCP, UDP, RTP, RTSP, HTTP, HTTPS, SMTP, FTP, DHCP, UPnP, DNS, DDNS |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
