Camera terminal expansion module - for AXIS M4215-V; M42 Series M4215-LV, M4218-LV
| Main Specifications | |
|---|---|
| Product Description | AXIS - camera terminal expansion module |
| Product Type | Camera terminal expansion module |
| Dimensions (WxDxH) | 1.6 in |
| Weight | 8.11 oz |
| Color | White, NCS S 1002-B |
| Manufacturer Warranty | 5-year warranty |
| Designed For | AXIS M4215-V; M42 Series M4215-LV, M4218-LV |
| General | |
| Product Type | Camera terminal expansion module |
| Height | 1.6 in |
| Weight | 8.11 oz |
| Enclosure Color | White, NCS S 1002-B |
| Expansion / Connectivity | |
| Interfaces | 1 x audio - line-in - mini-phone 3.5 mm ¦ 1 x audio - line-out - mini-phone 3.5 mm ¦ 1 x peripheral - input / output ¦ 1 x network / power - input - RJ-45 ¦ 1 x network / power - output - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | Mounting bracket, terminal block connector |
| Features | For indoor use, polycarbonate cover, portcast technology |
| Compliant Standards | EN55024, EN 61000-6-1, EMC, ICES-003 Class A, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, VCCI Class A, USGv6, BFR-free, EN 55032 Class A, RCM Class A, IEC/EN/UL 62368-1, IEEE 802.1x, PVC-free, IPv6, FCC Part 15 Subpart B, KS C 9832 Class A, KS C 9835, IPv4, CFR free, IEEE 802.1ar |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 122 °F |
| Compatibility Information | |
| Designed For | AXIS M4215-V ¦ AXIS M42 Series M4215-LV, M4218-LV |
