Barcode scanner - handheld - 2D imager - 60 frames / sec - decoded - USB
| Main Specifications | |
|---|---|
| Product Description | HP Engage 2D G2 Barcode Scanner - barcode scanner |
| Type | Barcode scanner - handheld - USB - decoded |
| Color | Ebony black |
| Minimum Bar Width | 3 mil |
| Scan Field Width | 0.79 in - 17.72 in |
| Scan Element Type | 2D imager - white LED |
| Sensor Resolution | 1280 x 800 |
| Scan Speed | 60 frames / sec |
| Connectivity Technology | Wired |
| Power | 5 V |
| System Requirements | Windows 11 Pro, Windows 10 Pro, Windows 10 IoT Enterprise 2021 LTSC, Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2016 LTSB, Ubuntu 20.04.1 LTS, Ubuntu 18.04.6, Ubuntu 20.04.4.0, Ubuntu 20.04.0.0, Red Hat Enterprise Linux 9.0, Debian 11.3.0, SUSE Linux Enterprise Server 12 SP5, SUSE Linux Enterprise 15 SP3 |
| Dimensions (WxDxH) | 1.7 in x 1.3 in x 6.3 in |
| Weight | 4.59 oz |
| General | |
| Type | Barcode scanner - handheld |
| Color | Ebony black |
| Expansion / Connectivity | |
| Interfaces | 1 x USB - Type A |
| Miscellaneous | |
| Included Accessories | Stand |
| Cables Included | 1 x USB cable - 6 ft |
| Compliant Standards | FCC Part 15 B, KCC, VCCI, IP42 |
| Power | |
| Voltage | 5 V |
| Electric Current Required | 255.76 mA (typical) |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
| System Requirements | |
| OS Required | Windows 11 Pro, Windows 10 Pro, Windows 10 IoT Enterprise 2021 LTSC, Windows 10 IoT Enterprise 2019 LTSC, Windows 10 IoT Enterprise 2016 LTSB, Ubuntu 20.04.1 LTS, Ubuntu 18.04.6, Ubuntu 20.04.4.0, Ubuntu 20.04.0.0, Red Hat Enterprise Linux 9.0, Debian 11.3.0, SUSE Linux Enterprise Server 12 SP5, SUSE Linux Enterprise 15 SP3 |
| Dimensions & Weight | |
| Width | 1.7 in |
| Depth | 1.3 in |
| Height | 6.3 in |
| Weight | 4.59 oz |
| Barcode | |
| Interface Type | USB |
| Minimum Bar Width | 3 mil |
| Scan Field Width | 0.79 in - 17.72 in |
| Scan Element Type | 2D imager - white LED |
| Sensor Resolution | 1280 x 800 |
| Frame Rate | 60 frames / sec |
| Skew (Degrees) | 60 |
| Pitch (Degrees) | 55 |
| Print Contrast Signal (PCS) | 20% |
| Decode Capability | AIM128, Codabar, Code 11, Code 39, Code 49, Code 93, Code 128, Code 16K, Coupon Code, FEBRABAN, GS1-128, GS1-128 Composites, GS1 DataBar, Industrial 2 of 5, Interleaved 2 of 5, ISBN, ISBT 128, ISSN, ITF-6, ITF-14, Matrix 25, MSI-Plessey, Plessey, Standard 2 of 5, UPC/EAN supplementals, Aztec code, Chinese Sensible Code, Code One, Data Matrix, GM Code, GS1 DataBar Expanded Stacked, GS1 DataBar Expanded Omni-directional, MaxiCode, MicroPDF417, PDF417, QR code, Australian Post, China Post, Kix (Netherlands) Post, Postal Code, Royal Mail, USPS Intelligent Mail, USPS Planet, USPS Postnet |
| TTL Decoding | Decoded |
| Connectivity Technology | Wired |
| Features | Data parsing, data formatter |
