Server - rack-mountable 2U - 2-way - no CPU - RAM 0 GB - SATA/PCI Express - hot-swap 2.5", 3.5" bay(s) - no HDD - AST2600 - 10 Gigabit Ethernet - no OS - monitor: none
| Main Specifications | |
|---|---|
| Product Description | ASUS RS720-E10-RS12E - rack-mountable no CPU - 0 GB - no HDD |
| Type | Server - rack-mountable |
| Height (Rack Units) | 2U |
| Server Scalability | 2-way |
| Processor | No CPU |
| Processor Socket | Socket P+ |
| RAM | 0 GB (installed) / 6 TB (max) - DDR4 SDRAM |
| Storage Controller | SATA (SATA 6Gb/s); NVMe (PCI Express (NVMe)) |
| Server Storage Bays | Hot-swap 2.5", 3.5" |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | ASPEED AST2600 |
| Video Memory | 64 MB |
| Networking | 10GbE |
| Power | (50/60 Hz) |
| Power Redundancy | Yes |
| OS Provided | No operating system |
| Dimensions (WxDxH) | 17.6 in x 33.1 in x 3.5 in |
| Weight | 40.11 lbs |
| General | |
| Type | Server |
| Product Form Factor | Rack-mountable - 2U |
| Server Scalability | 2-way |
| Hot-Swap Bays Qty | 12 |
| Expansion / Connectivity | |
| Bays | 12 (total) / 12 (free) x hot-swap 2.5" / 3.5" shared |
| Slots | 6 (total) / 6 (free) x PCIe 4.0 x16 - full-length, full-height (x16/x16/x16 or x8/x8/x8/x8/x8/x8 modes) ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 / Open Compute Project mezzanine (OCP) 3.0 ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, low-profile ¦ 2 (total) / 2 (free) x M.2 Card - 2260/2280 |
| Interfaces | 1 x VGA ¦ 2 x LAN (10Gigabit Ethernet) ¦ 4 x USB 3.2 Gen 1 (2 front, 2 rear) ¦ 1 x management - RJ-45 |
| Miscellaneous | |
| Included Accessories | ASMB10-iKVM Remote Management Card |
| Compliant Standards | FCC Class A certified, BSMI |
| RAM | |
| Installed Size | 0 GB (installed) / 6 TB (max) |
| Technology | DDR4 SDRAM |
| Form Factor | DIMM 288-pin |
| Slots | 32 (total) / 32 (empty) |
| Features | Registered, Load-Reduced DIMM (LRDIMM), 3DS Load-Reduced DIMM (LRDIMM), 3DS registered, 8-channel memory architecture, supports Intel Optane DC Persistent Memory (DCPMM) |
| RAM Supported | 6 TB registered |
| Networking | |
| Ethernet Ports | 2 x 10 Gigabit Ethernet |
| Ethernet Controller | Intel X710-AT2 |
| Data Link Protocol | 10 Gigabit Ethernet |
| Power | |
| Device Type | Power supply |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Voltage Required | AC 100-127/200-240 V (50/60 Hz) |
| Power Provided | 1600 Watt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Storage Controller | |
| Type | 1 x SATA |
| Controller Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | ASPEED AST2600 |
| Video Memory | 64 MB |
| Video Interfaces | VGA |
| Operating System / Software | |
| OS Provided | No operating system |
| Storage Controller (2nd) | |
| Type | 1 x NVMe |
| Controller Interface Type | PCI Express (NVMe) |
| Channel Qty | 8 |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.6 in |
| Depth | 33.1 in |
| Height | 3.5 in |
| Weight | 40.11 lbs |
| Processor / Chipset | |
| CPU | No CPU |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| CPU Socket | Socket P+ |
| Chipset Type | Intel C621A |
