Mini-dock - USB4 / Thunderbolt 4 - 2 x HDMI, DP - 1GbE
| Main Specifications | |
|---|---|
| Product Description | j5create Elite - mini-dock - USB4 / Thunderbolt 4 - 2 x HDMI, DP - 1GbE |
| Product Type | Mini-dock |
| Docking Interface | USB4 / Thunderbolt 4 |
| Video Interfaces | 2 x HDMI, DP |
| Dimensions (WxDxH) | 5.8 in x 2.2 in x 0.7 in |
| Weight | 4.36 oz |
| Color | Space gray |
| Networking | Gigabit Ethernet |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Product Type | Mini-dock |
| Width | 5.8 in |
| Depth | 2.2 in |
| Height | 0.7 in |
| Weight | 4.36 oz |
| Enclosure Color | Space gray |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SD Memory Card ¦ 1 (total) / 1 (free) x microSD |
| Interfaces | 1 x USB-C 3.2 Gen 1 with Power Delivery 3.0 (100 W) - 24 pin USB-C ¦ 2 x audio / video - HDMI output - 19 pin HDMI Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x USB-C 3.2 Gen 2 - 24 pin USB-C ¦ 1 x display / video - DisplayPort output - 20 pin DisplayPort (1.4) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x USB4 cable - integrated - 7.9 in |
| Features | Aluminum enclosure, MST (multi-stream transport), DisplayPort Alt Mode, USB-C powered |
| Compliant Standards | Plug and Play, E Mark |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Environmental Parameters | |
| Min Operating Temperature | 30.2 °F |
| Max Operating Temperature | 105.8 °F |
| Video | |
| Max Resolution Details | 3840 x 2160 - 60 Hz (Dual Display) ¦ 3840 x 2160 - 30 Hz (Triple Display (2 x HDMI / DisplayPort)) ¦ 2560 x 1440 - 144 Hz (HDMI only) ¦ 1920 x 1080 - 240 Hz (DisplayPort 1.4 only) |
| System Requirements | |
| OS Required | Apple MacOS, Microsoft Windows |
