Wireless access point - 1GbE, 2.5GbE - Wi-Fi 6 - 2.4 GHz, 5 GHz
| Main Specifications | |
|---|---|
| Product Description | NETGEAR WAX618 - wireless access point - Wi-Fi 6 |
| Device Type | Wireless access point |
| Form Factor | External |
| Localization | North America |
| Data Link Protocol | Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, 802.11ax |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum throughput (2.4 GHz): 600 Mbps ¦ Maximum throughput (5 GHz): 2400 Mbps |
| Included Accessories | Wall/ceiling mounting kit |
| Power Over Ethernet (PoE) Supported | PoE |
| Power | DC 12 V |
| Dimensions (WxDxH) | 9.5 in x 9.5 in x 1.6 in |
| Weight | 25.64 oz |
| Manufacturer Warranty | 5-year warranty |
| General | |
| Device Type | Wireless access point |
| Width | 9.5 in |
| Depth | 9.5 in |
| Height | 1.6 in |
| Weight | 25.64 oz |
| Localization | North America |
| Expansion / Connectivity | |
| Interfaces | 1 x 2.5 GBase-T (PoE) - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - 5 years ¦ Technical support - 90 days |
| Miscellaneous | |
| Included Accessories | Wall/ceiling mounting kit |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Data Transfer Rate | 3 Gbps |
| Data Link Protocol | Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, 802.11ax |
| Spread Spectrum Method | OFDM, OFDMA |
| Frequency Band | 2.4 GHz, 5 GHz |
| Performance | Maximum throughput (2.4 GHz): 600 Mbps ¦ Maximum throughput (5 GHz): 2400 Mbps |
| Wi-Fi Rating | AX3000 |
| Status Indicators | Power, LAN, 5 GHz, 2.4 GHz, cloud |
| Features | VLAN support, auto-uplink (auto MDI/MDI-X), repeating mode, MAC address filtering, Wireless Distribution System (WDS) support, Mesh networking, Wi-Fi Multimedia (WMM) support, bandwidth control, Captive Portal, Transmit Power Control (TPC), bridge mode, 2x2 MIMO technology, wireless access control, BSS Coloring, Guest Network, Neighbor AP detection, Block SSID Broadcast, Target Wake Time (TWT), Link Layer Discovery Protocol |
| Encryption Algorithm | SSL, PEAP, WPA, WPA2, WPA2-Enterprise, WPA3, WPA3-Enterprise, EAP-TLS, EAP-TTLS |
| Authentication Method | RADIUS |
| Compliant Standards | IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Device | Power injector |
| Voltage Required | DC 12 V |
| Power Consumption Operational | 21.2 watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Antenna | |
| Antenna | Internal |
