NAS server - 9 bays - rack-mountable - SATA 6Gb/s - RAID 0, 1, 5, 6, 10, JBOD - RAM 16 GB - 2.5 Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 1U
| Main Specifications | |
|---|---|
| Product Description | QNAP TS-H987XU-RP - NAS server |
| Device Type | NAS server |
| Host Connectivity | 2.5 Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 1U |
| Installed Devices / Modules Qty | 0 (installed) / 9 (max) |
| Dimensions (WxDxH) | 16.9 in x 18.9 in x 1.7 in |
| Weight | 18.58 lbs () |
| Localization | United States |
| Processor | 1 x Intel Xeon E-2334 3.4 GHz (Quad-Core) |
| Storage Controller | RAID SATA 6Gb/s RAID 0, 1, 5, 6, 10, JBOD |
| Networking | 100Mb LAN, 1GbE, 10GbE, 5GbE, 2.5GbE |
| Performance | Concurrent connections (CIFS): 11000 - (with maximum memory) |
| RAM | 16 GB |
| Power Redundancy | Yes |
| Storage Operating System | QNAP QuTS hero h5.0.1 / QTS 5.0.1 |
| System Requirements | Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Microsoft Windows Server 2016, CentOS 7.0, Microsoft Windows Server 2019, SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11, Apple macOS 10.10 or later |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | NAS server |
| Host Connectivity | 2.5 Gigabit Ethernet / 10 Gigabit Ethernet |
| Enclosure Type | Rack-mountable - 1U |
| Total Storage Capacity | 0 GB |
| Installed Devices / Modules Qty | 0 (installed) / 9 (max) |
| Width | 16.9 in |
| Depth | 18.9 in |
| Height | 1.7 in |
| Weight | 18.58 lbs () |
| Localization | United States |
| Expansion / Connectivity | |
| Expansion Bays | 4 (total) / 4 (free) x hot-swap - 3.5" ¦ 5 (total) / 5 (free) - 2.5" |
| Expansion Slots | 4 (total) / 3 (free) x DIMM 288-pin ¦ 1 x PCI Express 4.0 x8 |
| Interfaces | 2 x Ethernet 10Gb ¦ 2 x 2.5 Gigabit Ethernet ¦ 4 x USB 3.2 Gen 2 - Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years ¦ Limited warranty - accessories - 1 year |
| Miscellaneous | |
| Cables Included | 1 x network cable |
| Features | Reset button, dual boot, built-in 4 x 40 mm cooling fans |
| Included Accessories | 16 x flat head screws (for 3.5" HDD), 36 x flat head screws (for 2.5" HDD), 2 x power cables |
| Networking | |
| Data Link Protocol | 100Mb LAN, 1GbE, 10GbE, 5GbE, 2.5GbE |
| Network / Transport Protocol | FTP, DDNS, SFTP, IPv4, IPv6, TFTP |
| Remote Management Protocol | SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH, RADIUS |
| Network Services Compatibility | Microsoft CIFS, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), Network File System v3 (NFS v3), Network File System v4 (NFS v4) |
| Performance | Concurrent connections (CIFS): 11000 - (with maximum memory) |
| Features | Firewall protection, VLAN support, WOL, antivirus analysis, DHCP server, Domain Controller, port trunking, SSD trim, Windows ODX, FXP support, hybrid backup sync, Qfiling, Qsirch, SQL Server, VJBOD Cloud, Qsync, QuMagie, Smart Fan, QmailAgent, QuWAN, Shared Folder Snapshot, LDAP server, Storage Pool, SED Storage Pool, JBOD Expansion, Disk, Enclosure Locate, Disk S.M.A.R.T. Scan, Disk S.M.A.R.T. Data Migration, Disk Roaming, Disk Standby, Snapshot Retention Policy, Self-serve Snapshot Recovery, Application Consisted Snapshot, Snapshot Full Clone, Snapshot Replica / Vault, SSD read-only Cache, External Device Management, MTP, shared folder permission, group quota, folder quota, home folder, Resource Monitor, Virtual Switch, Allow/Deny List, Access Protection, Service binding, DA Driver Analyzer, floating point unit, SSD cache acceleration support, fibre channel service, block-based iSCSI LUN, LUN mapping, LUN masking, WWPN Aliases Import/Export, FC Port Group, FC Port Binding, MPIO, online LUN capacity expansion, LUN snapshot, auto tiering, RAID Hot Spare, RAID Sync/Rebuild/Scrubbing, SSD life estimation, domain security, security counselor, malware remover, 2-step verification, HybridMount, Hyper Data Protector, Boxafe, Windows ACL, schedule on/off, iSCSI service, media streaming add-on, Secure Erase, QVPN Service, End-to-End Data Integrity, Snapshot Instant Clone, SSD read & write log cache, SSD dedicated ZIL cache, External RAID Device Management, Shared Folder WORM, user quota management |
| Encryption Algorithm | AES-NI |
| Power | |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Power Consumption Operational | 120.58 Watt |
| Power Provided | 300 Watt |
| Software / System Requirements | |
| Storage Operating System | QNAP QuTS hero h5.0.1 / QTS 5.0.1 |
| Software Included | IronWolf Health Management |
| OS Required | Microsoft Windows Server 2008 R2, IBM AIX 7, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Ubuntu 14.04, Red Hat Enterprise Linux 6.6, Microsoft Windows Server 2016, CentOS 7.0, Microsoft Windows Server 2019, SuSE Linux 12 or later, Oracle Solaris 10 or later, Microsoft Windows 7 / 8 / 10 / 11, Apple macOS 10.10 or later |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
| Storage Controller | |
| Type | RAID |
| Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD |
| Processor / Memory | |
| Processors Installed | 1 x Intel Xeon E-2334 3.4 GHz |
| Number of Cores | Quad-Core |
| Max Supported Qty | 1 |
| Max Turbo Speed | 4.8 GHz |
| RAM | 16 GB (installed) / 128 GB (supported) - DDR4 |
| Features | Unbuffered, ECC |
| Flash Memory Installed | 5 GB |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 24.47 lbs |
