Network extender - 1GbE - 10Base-T, 100Base-TX, 1000Base-T - RJ-45 / 2 x RJ-45 - up to 328 ft
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series 2Port Gigabit waterproof Hardened and vandal-proof PoE extender/Repeater, 95W in 2x 30W out, IP67 and IK10, 100M - network extender - 1GbE, 100Mb LAN, 10Mb LAN |
| Device Type | Network extender - RJ-45 / 2 x RJ-45 |
| Form Factor | Desktop / wall mountable |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Link Protocol | 1GbE, 100Mb LAN, 10Mb LAN |
| Max Transfer Distance | 328 ft |
| Power Over Ethernet (PoE) | PoE+ |
| Dimensions (WxDxH) | 2.8 in x 1.7 in x 5.9 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Network extender |
| Form Factor | Desktop / wall mountable |
| Color | Silver |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-T (input) - RJ-45 ¦ 2 x Ethernet 1000Base-T (output) - RJ-45 - 95 W |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | 3 x waterproof cable connectors |
| Compliant Standards | IP67, IK10, RoHS, REACH, FCC, WEEE |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Link Protocol | 1GbE, 100Mb LAN, 10Mb LAN |
| Max Transfer Distance | 328 ft |
| Features | 95W PoE power budget |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3, IEEE 802.3ab, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x |
| Power | |
| Power Over Ethernet (PoE) | PoE+ |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Dimensions & Weight | |
| Width | 2.8 in |
| Depth | 1.7 in |
| Height | 5.9 in |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 9.8 in |
| Shipping Depth | 7.9 in |
| Shipping Height | 3.3 in |
