10/100/1000 Mbps, RJ45/SC Singlemode, -10° to 60°C, 10 km (6.2 mi.) - Fiber media converter - 1GbE - over CAT 5/5e/6/6a - 10Base-T, 100Base-TX, 1000Base-T - RJ-45 / SC single-mode - up to 6.2 miles - 1310 nm - TAA Compliant
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series Hardened Gigabit Copper to Fiber Media Converter - 10/100/1000 Mbps, RJ45/SC Singlemode, -10° to 60°C, 10 km (6.2 mi.) - fiber media converter - 10Mb LAN, 100Mb LAN, 1GbE - TAA Compliant |
| Device Type | Fiber media converter - RJ-45 / SC single-mode |
| Form Factor | External |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 nm |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Transmission Medium | CAT 5/5e/6/6a |
| Max Transfer Distance | 6.2 miles |
| Power Over Ethernet (PoE) | PoE |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 2.9 in x 4.3 in x 0.9 in |
| Weight | 8.46 oz |
| TAA Compliant | Yes |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Fiber media converter |
| Form Factor | External |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x Ethernet 1000 - SC single-mode female x 2 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | L-shape rack mount brackets, 2 x connector caps |
| Mounting Kit | Included |
| Compliant Standards | RoHS, FCC, LPS, UL, WEEE, cUL |
| TAA Compliant | Yes |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Data Transfer Rate | 1 Gbps |
| Optical Wave Length | 1310 nm |
| Max Transfer Distance | 6.2 miles |
| Status Indicators | Power, link/activity, status |
| Features | Auto-uplink (auto MDI/MDI-X), hardened |
| Compliant Standards | IEEE 802.3ab, IEEE 802.3, IEEE 802.3u, IEEE 802.3z |
| Power | |
| Power Over Ethernet (PoE) | PoE |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 1.8 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 2.9 in |
| Depth | 4.3 in |
| Height | 0.9 in |
| Weight | 8.46 oz |
