Multimode, 4x Duplex LC, 70/30 Split - Tap splitter - 100GbE, 40GbE - 850 nm
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series Fiber TAP Cassette - Multimode, 4x Duplex LC, 70/30 Split - tap splitter - 100GbE, 40GbE |
| Device Type | Tap splitter |
| Form Factor | Plug-in module |
| Optical Wave Length | 850 nm |
| Data Link Protocol | 100GbE, 40GbE |
| Dimensions (WxDxH) | 3.5 in x 1.2 in x 4.7 in |
| Manufacturer Warranty | Limited lifetime warranty |
| General | |
| Device Type | Tap splitter |
| Form Factor | Plug-in module |
| Expansion / Connectivity | |
| Interfaces | 4 x (input) - LC multi-mode female x 2 ¦ 4 x (output) - LC multi-mode female x 2 ¦ 4 x (monitoring) - LC multi-mode female x 2 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Compliant Standards | RoHS, OM4, REACH |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | 100GbE, 40GbE |
| Optical Wave Length | 850 nm |
| Features | 70:30 split ratio, passive Tap mode |
| Compliant Standards | IEEE 802.3ae, ANSI T11.2 |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 85% (non-condensing) |
| Dimensions & Weight | |
| Width | 3.5 in |
| Depth | 1.2 in |
| Height | 4.7 in |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 7.9 in |
| Shipping Depth | 4.7 in |
| Shipping Height | 2 in |
| Shipping Weight | 7.05 oz |
