Fiber media converter - 1GbE - 10Base-T, 100Base-TX, 1000Base-T - RJ-45 / SFP (mini-GBIC) - up to 328 ft - for P/N: N001-025-BK, N201-025-BL, N286-01GLX-SLX, N286-01GSX-MDLC
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series Gigabit SFP Fiber to Ethernet Media Converter, POE+, International Power Cables, 10/100/1000 Mbps - fiber media converter - 10Mb LAN, 100Mb LAN, 1GbE |
| Device Type | Fiber media converter - RJ-45 / SFP (mini-GBIC) |
| Form Factor | External |
| Localization | Australia, United Kingdom, North America, Europe |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Transfer Rate | 1 Gbps |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Max Transfer Distance | 328 ft |
| Power Over Ethernet (PoE) | PoE+ |
| Power | AC 100-240 V |
| Dimensions (WxDxH) | 3.7 in x 2.8 in x 1 in |
| Manufacturer Warranty | 2-year warranty |
| Designed For | P/N: N001-025-BK, N201-025-BL, N286-01GLX-SLX, N286-01GSX-MDLC |
| General | |
| Device Type | Fiber media converter |
| Form Factor | External |
| Color | Black |
| Localization | Australia, United Kingdom, North America, Europe |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 female ¦ 1 x Ethernet 1000Base-X - SFP female |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Included Accessories | 4 power plug adapters |
| Cables Included | Power cable - 3.6 ft |
| Compliant Standards | Plug and Play, Mexico NOM, RoHS, RoHS3, REACH, UKCA, WEEE, FCC |
| Networking | |
| Connectivity Technology | Wired |
| Cabling Type | 10Base-T, 100Base-TX, 1000Base-T |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, 1GbE |
| Data Transfer Rate | 1 Gbps |
| Max Transfer Distance | 328 ft |
| Status Indicators | Power, link/activity, port transmission speed, status, PoE |
| Features | Half duplex mode, full duplex mode, Automatic Media-Dependent Interface Crossover (MDIX), Link Fault Pass Through function (LFP) |
| Compliant Standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3z |
| Power | |
| Power Over Ethernet (PoE) | PoE+ |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | -4 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 90% RH (non-condensing) |
| Dimensions & Weight | |
| Width | 3.7 in |
| Depth | 2.8 in |
| Height | 1 in |
| Compatibility Information | |
| Designed For | P/N: N001-025-BK, N201-025-BL, N286-01GLX-SLX, N286-01GSX-MDLC |
