60W USB-C, 2x 20W USB-C, 3x USB-A, PD Charging, Device and Apple Watch Storage - Charging station + AC power adapter - 60 Watt - 3 A - PD 2.0 - 6 output connectors (3 x USB Type A, 3 x USB-C) - black - North America - for P/N: M100-003-HD, M100-006-GY-MAX, M100-010-BK, M110-003-WH, U326-001-BK, U326-001-BK-10
| Main Specifications | |
|---|---|
| Product Description | Eaton Tripp Lite Series 6-Port USB Charging Station - 60W USB-C, 2x 20W USB-C, 3x USB-A, PD Charging, Device and Apple Watch Storage charging station - + AC power adapter - 3 x USB Type A, 3 x USB-C - 60 watt |
| Product Type | Charging station + AC power adapter |
| Designed For | Notebook, cellular phone, smart watch, tablet |
| Dimensions (WxDxH) | 7.3 in x 4.4 in x 1.4 in |
| Weight | 8.66 oz |
| Color | Black |
| Localization | North America |
| Output Connector Type | Total 6: 3 x USB Type A, 3 x USB-C |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Voltage Provided | 5 / 9 / 12 / 15 / 20 V |
| Max Electric Current | 3 A |
| Fast Charge Technology | Power Delivery 2.0 |
| Power Provided | 60 watt |
| Power Device Details | 3 x 4 pin USB Type A - 5 V - 12 W - 2.4 A ¦ 2 x 24 pin USB-C - 20 W ¦ 24 pin USB-C - 20 V - 60 W - 3 A ¦ AC power adapter - 20 V - 120 W - 6 A |
| Cables | Power cable - 3.3 ft |
| Manufacturer Warranty | 1-year warranty |
| Designed For | P/N: M100-003-BK, M100-003-HD, M100-003-WH, M100-006-BK, M100-006-GY-MAX, M100-006-WH, M100-010-BK, M102-003-HD, M102-006-HD, M110-003-WH, U040-003-C-5A, U326-001-BK, U326-001-BK-10, UR030-003, UR030-003-DNB, UR030-003-LAB, UR030-003-RAB, UR030-003-UPB, UR050-001-24G |
| General | |
| Product Type | Charging station + AC power adapter |
| Designed For | Notebook, cellular phone, smart watch, tablet |
| Width | 7.3 in |
| Depth | 4.4 in |
| Height | 1.4 in |
| Weight | 8.66 oz |
| Enclosure Color | Black |
| Localization | North America |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Miscellaneous | |
| Packaging Type | Box |
| Material | Plastic |
| Included Accessories | 10 storage brackets |
| Cables Included | Power cable - 3.3 ft |
| Compliant Standards | FCC, ICES, NOM, REACH, RoHS, WEEE |
| Power Device | |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Input Connectors | Power NEMA 1-15P |
| Input Connectors Qty | 1 |
| Voltage Provided | 5 / 9 / 12 / 15 / 20 V |
| Output connectors | Total 6: 3 x 4 pin USB Type A, 3 x 24 pin USB-C |
| Power Provided | 60 watt |
| Max Electric Current | 3 A |
| Power Device Details | 3 x 4 pin USB Type A - 5 V - 12 W - 2.4 A ¦ 2 x 24 pin USB-C - 20 W ¦ 24 pin USB-C - 20 V - 60 W - 3 A ¦ AC power adapter: - 20 V - 120 W - 6 A |
| Fast Charge Technology | Power Delivery 2.0 |
| AC Power Adapter Included | Yes |
| Features | Power LED Indicator, Quick Charge Mode, overload protection, overcharging protection |
| Compatibility Information | |
| Designed For | P/N: M100-003-BK, M100-003-HD, M100-003-WH, M100-006-BK, M100-006-GY-MAX, M100-006-WH, M100-010-BK, M102-003-HD, M102-006-HD, M110-003-WH, U040-003-C-5A, U326-001-BK, U326-001-BK-10, UR030-003, UR030-003-DNB, UR030-003-LAB, UR030-003-RAB, UR030-003-UPB, UR050-001-24G |
