Wireless router - WWAN 1GbE 2.4 GHz - 4G, 3G - wall-mountable, pole-mountable
| Main Specifications | |
|---|---|
| Product Description | Zyxel LTE7461-M602 - wireless router - WWAN - Wi-Fi, LTE - 4G, 3G - wall-mountable, pole-mountable |
| Device Type | Wireless router - wireless cellular modem |
| Enclosure Type | Wall-mountable, pole-mountable |
| Cellular Protocol | LTE, WCDMA |
| Generation | 4G, 3G |
| Cellular Band | LTE B12, LTE B13, LTE B2, LTE B25, LTE B26, LTE B29, LTE B4, LTE B5, LTE B66, LTE B7, WCDMA B2, WCDMA B4, WCDMA B5 |
| WAN Ports Qty | 1 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, LTE |
| Frequency Band | 2.4 GHz |
| Network / Transport Protocol | IPv6, IPv4, DDNS |
| Remote Management Protocol | ICMP, SSH, TR-069, CLI, TR-143 |
| Features | 2x2 MIMO technology, NDP, DHCP server, VPN passthrough, NAPT support, NAT support, DMZ support, port forwarding, port triggering, ALG support, bridge mode, router mode, IP address filtering, MAC address filtering, URL filtering, SPI, DoS attack prevention, firmware upgradable, APN management, UPnP Internet Gateway Device, LTE Band Pilot System management compatible, PoE powered, WPS button, hidden SSID, reset button |
| Compliant Standards | IEEE 802.3af |
| Dimensions (WxDxH) | 10 in x 10 in x 2.3 in |
| Weight | 2.43 lbs |
| General | |
| Device Type | Wireless router |
| Enclosure Type | Wall-mountable, pole-mountable |
| Connectivity Technology | Wired, wireless |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, LTE |
| Frequency Band | 2.4 GHz |
| Network / Transport Protocol | IPv6, IPv4, DDNS |
| Remote Management Protocol | ICMP, SSH, TR-069, CLI, TR-143 |
| Features | 2x2 MIMO technology, NDP, DHCP server, VPN passthrough, NAPT support, NAT support, DMZ support, port forwarding, port triggering, ALG support, bridge mode, router mode, IP address filtering, MAC address filtering, URL filtering, SPI, DoS attack prevention, firmware upgradable, APN management, UPnP Internet Gateway Device, LTE Band Pilot System management compatible, PoE powered, WPS button, hidden SSID, reset button |
| Compliant Standards | IEEE 802.3af, 3GPP UE Category 6, IP68, ITU-T K.21, FCC, IC |
| Status Indicators | Power, Internet, Wi-Fi |
| Expansion / Connectivity | |
| Interfaces | LAN: 1 x 10Base-T/100Base-TX/1000Base-T |
| Expansion Slots | 1 (total) / 1 (free) x Micro-SIM |
| Miscellaneous | |
| Included Accessories | Cable gland, pole/wall mount kit |
| Cables Included | 1 x network cable ¦ 1 x power cable |
| Power | |
| Power Consumption Operational | 13 watt |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Communications | |
| Type | Wireless cellular modem |
| Cellular Protocol | LTE, WCDMA |
| Generation | 4G, 3G |
| Cellular Band | LTE B12, LTE B13, LTE B2, LTE B25, LTE B26, LTE B29, LTE B4, LTE B5, LTE B66, LTE B7, WCDMA B2, WCDMA B4, WCDMA B5 |
| Dimensions & Weight | |
| Width | 10 in |
| Depth | 10 in |
| Height | 2.3 in |
| Weight | 2.43 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 16.5 in |
| Shipping Depth | 11 in |
| Shipping Height | 4.3 in |
| Shipping Weight | 6.72 lbs |
| Antenna | |
| Antenna | Internal |
| Antenna Qty | 2 |
| Gain Level | 8 dBi |
| Line Properties | |
| Line Coding Format | 64 QAM, QPSK, 16 QAM |
