Intel Core i5 - 12500H / up to 4.5 GHz - Win 10 Pro 64-bit (includes Win 11 Pro License) - Intel Iris Xe Graphics - 8 GB RAM - 256 GB SSD NVMe - 14" 1920 x 1200 - NFC, Wi-Fi 6E - BTS - with 1 Year Hardware Service with Onsite/In-Home Service After Remote Diagnosis - Disti SNS
| Main Specifications | |
|---|---|
| Product Description | Dell Precision 5470 - 14" - Intel Core i5 - 12500H - 8 GB RAM - 256 GB SSD |
| Product Type | Mobile workstation |
| Operating System | Win 10 Pro 64-bit + Windows 11 Pro License - English / French / Spanish |
| Processor | Intel Core i5 (12th Gen) - 12500H / 2.5 GHz, up to 4.5 GHz / 18 MB Cache |
| Memory | 8 GB LPDDR5 (provided memory is soldered) |
| Storage | 256 GB SSD - NVMe |
| Display | 14" WLED 1920 x 1200 / WUXGA @ 60 Hz - 161 ppi |
| Graphics | Intel Iris Xe Graphics |
| Input Device | Keyboard, touchpad |
| Keyboard Backlight | Yes |
| Integrated Webcam | Yes |
| Networking | Bluetooth, NFC, 802.11a/b/g/n/ac/ax (Wi-Fi 6E) |
| Battery | 4-cell |
| Features | Accelerometer, ambient light sensor, hall sensor |
| Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip, smart card reader, contactless smart card reader |
| Dimensions (WxDxH) | 12.2 in x 8.3 in x 0.4 in |
| Weight | 3.26 lbs |
| Pricing Type | Build To Stock (BTS) |
| Manufacturer Selling Program | Dell Smart Selection |
| Environmental Standards | TCO Certified Notebooks 9, ENERGY STAR Qualified EPEAT Gold |
| Carbon Footprint | 395 kg carbon emissions |
| Bundled Services | 1 Year Hardware Service with Onsite/In-Home Service After Remote Diagnosis - Disti SNS |
| General | |
| Product Type | Mobile workstation |
| Operating System | Windows 10 Pro 64-bit Edition + Windows 11 Pro License - English / French / Spanish |
| Memory | |
| RAM | 8 GB (provided memory is soldered) |
| Technology | LPDDR5 SDRAM |
| Speed | 5200 MHz |
| Rated Speed | 5200 MHz |
| Manufacturer Warranty | |
| Bundled Services | 1 Year Hardware Service with Onsite/In-Home Service After Remote Diagnosis - Disti SNS |
| Miscellaneous | |
| Integrated Options | Accelerometer, ambient light sensor, hall sensor |
| Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip, smart card reader, contactless smart card reader |
| Features | ExpressCharge |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Security Slot Type | Noble Wedge security slot |
| Included Accessories | USB-C power adapter |
| Compliant Standards | FIPS 140-2 |
| Pricing Type | Build To Stock (BTS) |
| Manufacturer Selling Program | Dell Smart Selection |
| Storage | |
| Main Storage | 256 GB SSD M.2 2230 PCIe 3.0 x4 - NVM Express (NVMe) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Shock Tolerance (operating) | 110 g @ 2 ms half-sine pulse |
| Shock Tolerance (non-operating) | 160 g @ 2 ms half-sine pulse |
| Vibration Tolerance (operating) | 0.66 g @ RMS (random) |
| Vibration Tolerance (non-operating) | 1.3 g @ RMS (random) |
| Software | |
| Software Included | Dell Applications for Windows 10 |
| Battery | |
| Technology | 4-cell lithium ion |
| Capacity | 72 Wh |
| Display | |
| Type | 14" |
| LCD Backlight Technology | WLED backlight |
| Resolution | 1920 x 1200 (WUXGA) |
| V-Sync Rate at Max Res. | 60 Hz |
| Widescreen | Yes |
| Pixel Density (ppi) | 161 |
| Image Aspect Ratio | 16:10 |
| Image Brightness | 500 cd/m² |
| Color Gamut | 100% sRGB |
| Features | Anti-glare, Wide Viewing Angle, 35 ms response rate, Low Blue Light technology, ±88° vertical viewing angle, ±88° horizontal viewing angle, 0.1572 mm pixel pitch |
| Communications | |
| Wireless | Bluetooth, NFC, 802.11a/b/g/n/ac/ax (Wi-Fi 6E) |
| Wireless Controller | Intel Wi-Fi 6E AX 211 |
| Features | Dual stream (2x2) |
| Dimensions & Weight | |
| Dimensions (WxDxH) | 12.2 in x 8.3 in x 0.4 in |
| Weight | 3.26 lbs |
| Processor / Chipset | |
| CPU | Intel Core i5 (12th Gen) 12500H / 2.5 GHz |
| Max Turbo Speed | 4.5 GHz |
| Number of Cores | 12-core |
| Cache | 18 MB |
| Features | Intel Smart Cache, Intel Deep Learning Boost (DL Boost) |
| Audio & Video | |
| Graphics Processor | Intel Iris Xe Graphics |
| Camera | Yes - 1280 x 720 (standard), 640 x 400 (infrared) |
| Resolution | 0.92 Megapixel (standard), 0.25 Megapixel (infrared) |
| Image Sensor Type | CMOS |
| Video Resolutions | 1280 x 720 |
| Frame Rate | 30 frames per second |
| Camera Features | IR camera, RGB camera, 75.8 degrees |
| Sound | Two tweeters, two woofers, dual array microphone |
| Codec | Realtek ALC711-VD |
| Input | |
| Type | Keyboard, touchpad |
| Keyboard Backlight | Yes |
| AC Adapter | |
| Input | AC 100-240 V (50/60 Hz) |
| Output | 90 Watt, 5 / 9 / 15 / 20 V |
| Connections & Expansion | |
| Interfaces Details | 4 x USB4 (supports Thunderbolt 4, DisplayPort 1.4 Alt Mode) (Power Delivery) ¦ Headphone/microphone combo jack |
| Memory Card Reader | Yes (microSD, microSDHC, microSDXC) |
| Sustainability Information | |
| TCO Certified | - TCO Certified Notebooks 9 |
| EPEAT Compliant | EPEAT Gold |
| ENERGY STAR Certified | Yes |
| Carbon Footprint | 395 kg carbon emissions |
| Total CF/unit Standard Deviation (kg CO2e) | 88 |
| Manufacturing (kg CO2e) | 349.575 |
| Logistics (kg CO2e) | 13.035 |
| Use (kg CO2e) | 30.81 |
| EOL (kg CO2e) | 1.58 |
| Total Carbon w/o Use Phase (kg CO2e) | 364.19 |
| PAIA Version | 1.3.1, 2022 |
