KVM / audio extender - HDMI, USB 2.0 - over CAT 5/6/6a/7 - USB - up to 230 ft
| Main Specifications | |
|---|---|
| Product Description | SIIG HDMI KVM Extender with Touch Screen - KVM / audio extender - HDMI, USB 2.0 |
| Device Type | KVM / audio extender - USB |
| Form Factor | External |
| Data Transfer Rate | 18 Gbps |
| Data Link Protocol | HDMI, USB 2.0 |
| Transmission Medium | CAT 5/6/6a/7 |
| Max Transfer Distance | 230 ft |
| Power | AC 100-240 V |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | KVM / audio extender |
| Form Factor | External |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x HDMI output (transmitter) - 19 pin HDMI Type A ¦ 1 x HDMI input (transmitter) - 19 pin HDMI Type A ¦ 1 x USB (transmitter) - Type A ¦ 1 x TOSLINK (receiver) - TOSLINK ¦ 1 x HDMI output (receiver) - 19 pin HDMI Type A ¦ 1 x USB keyboard (receiver) - Type A ¦ 1 x USB mouse (receiver) - Type A |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Compliant Standards | HDCP 2.2, UL, FCC, RoHS |
| Networking | |
| Connectivity Technology | Wired |
| Data Link Protocol | HDMI, USB 2.0 |
| Data Transfer Rate | 18 Gbps |
| Keyboard / Mouse Interface | USB |
| Max Resolution | 3840 x 2160 @ 60 Hz |
| Max Transfer Distance | 230 ft |
| Features | Reset button, HDMI loop out, 5.1 channel audio support, near zero latency, ESD Protector, 4K resolution support, 1080i resolution support, 1080p resolution support, 720p resolution support, DTS support |
| Compliant Standards | HDCP 2.2 |
| Power | |
| Power Device | External power adapter |
| Installed Qty | 2 |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 14 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Dimensions & Weight | |
| Dimensions (WxDxH) / Weight Details | Transmitter: 6 in x 4.1 in x 0.9 in / 12.3 oz ¦ Receiver: 6 in x 4.1 in x 0.9 in / 12.3 oz |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 14.1 in |
| Shipping Depth | 6 in |
| Shipping Height | 3.4 in |
| Shipping Weight | 2.73 lbs |
