Hard drive array - 288 TB - 16 bays (SATA-600 / SAS-3) - HDD 18 TB x 16 - SAS 12Gb/s (external) - rack-mountable - 3U
| Main Specifications | |
|---|---|
| Product Description | Promise Vess R3000 Series R3600TID - hard drive array |
| Device Type | Hard drive array |
| Enclosure Type | Rack-mountable - 3U |
| Total Array Capacity | 288 TB |
| Interface | SAS 12Gb/s |
| Installed Devices / Modules Qty | 16 (installed) / 16 (max) |
| Supported Drives | SATA-600 / SAS-3 |
| Storage Controller | RAID (SATA 6Gb/s / SAS 12Gb/s) - RAID 0, 1, 5, 6, 10, 50, 60 |
| Storage Controller Quantity | 2 |
| Hard Drive | 16 x 18 TB HDD - hot-swap |
| OS Required | Apple macOS Sierra 10.12.6 or later, Apple macOS Ventura 13.1, Microsoft Windows Server 2008 R2 SP1, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Linux 7.2, SuSE Linux Enterprise Server 11 SP4, SuSE Linux Enterprise Server 12 SP1, VMware ESXi 6.0, VMware ESXi 6.5, VMware ESXi 7.0, VMware ESXi 8.0, VMware ESXi 6.7, Citrix Hypervisor 7.1 LTSR, Citrix Hypervisor 8.2 LTSR, Citrix Hypervisor 8.0, Citrix Hypervisor 8.1, Citrix Hypervisor 7.0 LTSR |
| Power | AC 100-240 / DC 180-320 V |
| Dimensions (WxDxH) | 17.6 in x 20 in x 5.2 in |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | Hard drive array |
| Enclosure Type | Rack-mountable - 3U |
| Expansion / Connectivity | |
| Expansion Bays | 16 (total) / 0 (free) x hot-swap - 3.5" |
| Interfaces | 4 x Ethernet 1000 ¦ 2 x Ethernet 10Gb ¦ 1 x SAS 12Gb/s - Mini SAS HD (SFF-8644) ¦ 1 x serial (management) - RJ-11 ¦ 1 x Ethernet 1000 (management) - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Features | Media Patrol, Foreground RAID Initialization, Redundancy Check, Background Synchronizing, rebuild, UPS status monitoring, S.M.A.R.T. support, Predictive Data Migration (PDM), LUN masking and mapping, SSD cache, Intelligent Bad Sector Remapping, NVRAM error logging, LDAP support, Active Directory support, SNMP support |
| Compliant Standards | VCCI, FCC, BSMI, RCM, CB, NTRL |
| RAM | |
| Installed Size | 8 GB |
| Storage | |
| Total Array Capacity | 288 TB |
| HDD Array External Interface | SAS 12Gb/s |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 / DC 180-320 V |
| Power Provided | 550 Watt |
| 80 PLUS Certification | 80 PLUS |
| Environmental Parameters | |
| Min Operating Temperature | 41 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Sound Emission | 60 dB |
| Storage Controller | |
| Type | RAID (SAS-3) |
| Installed Qty | 2 |
| Interface Type | SATA 6Gb/s / SAS 12Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60 |
| System Requirements | |
| OS Required | Apple macOS Sierra 10.12.6 or later, Apple macOS Ventura 13.1, Microsoft Windows Server 2008 R2 SP1, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2019, Microsoft Windows Server 2022, Red Hat Linux 7.2, SuSE Linux Enterprise Server 11 SP4, SuSE Linux Enterprise Server 12 SP1, VMware ESXi 6.0, VMware ESXi 6.5, VMware ESXi 7.0, VMware ESXi 8.0, VMware ESXi 6.7, Citrix Hypervisor 7.1 LTSR, Citrix Hypervisor 8.2 LTSR, Citrix Hypervisor 8.0, Citrix Hypervisor 8.1, Citrix Hypervisor 7.0 LTSR |
| Storage Controller (2nd) | |
| Installed Qty | 2 |
| Hard Drive | |
| Type | HDD - hot-swap |
| Capacity | 16 x 18 TB |
| Dimensions & Weight | |
| Width | 17.6 in |
| Depth | 20 in |
| Height | 5.2 in |
| Chassis | |
| Installed Devices / Modules Qty | 16 |
| Supported Devices / Modules Qty | 16 |
| Supported Drives | SATA-600 / SAS-3 |
