All-in-one collaboration videobar - Zoom Certified - power adapter included
| Main Specifications | |
|---|---|
| Product Description | Sharp PN-ZCMS1 - power adapter included |
| Device Type | All-in-one collaboration videobar |
| EU Data Act | Https://www.sharpconsumer.com/data-access-request/ |
| Codec | H.264, MJPG, YUY2 |
| Video Input | Digital camera - USB 2.0 |
| Audio Input | 6-microphone array |
| Audio Output | Speaker(s) |
| Power | AC 100-240 V (50/60 Hz) |
| Software Certification | Zoom Certified |
| System Requirements | Windows 8.1, Windows 10, Windows 11, Apple macOS 10.15, Apple macOS 11, Apple macOS 12 |
| General | |
| Device Type | All-in-one collaboration videobar |
| EU Data Act | Https://www.sharpconsumer.com/data-access-request/ |
| Video Codecs | H.264, MJPG, YUY2 |
| Dimensions & Weight Details | Video sound bar excluding protrusions - Width 18.2 in Depth 3 in Height 3.7 in Weight 33.5 oz |
| Built-in Devices | Speaker, camera, 6 microphone array |
| Expansion / Connectivity | |
| Interfaces | 1 x USB-C 2.0 - 24 pin USB-C ¦ 1 x audio - input / output |
| Miscellaneous | |
| Cables Included | 1 x USB-C to USB-A cable |
| Mounting Kit | Included |
| Included Accessories | Wall mount bracket, remote control, CR2032 battery, power adapter, lens cap, screws |
| Software Certification | Zoom Certified |
| Power | |
| Power Device | Power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 36 watt |
| Software / System Requirements | |
| OS Required | Windows 8.1, Windows 10, Windows 11, Apple macOS 10.15, Apple macOS 11, Apple macOS 12 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Audio Output | |
| Type | Speaker(s) |
| Output Power / Channel | 8 watt |
| Audio Input | |
| Type | 6-microphone array - integrated |
| Video Input | |
| Type | Digital camera - integrated |
| Interface Type | USB 2.0 |
| Digital Video Capture Resolution | 3840 x 2160, 2560 x 1440, 1920 x 1080, 1280 x 720, 1024 x 576, 960 x 540, 800 x 600, 640 x 480, 640 x 360, 480 x 270, 352 x 288, 320 x 240, 320 x 180, 176 x 144, 160 x 120, 160 x 90 |
| Video Modes | 4K |
| Digital Zoom | 5 |
| Features | 12 megapixels, echo cancelation, face detection, voice localization, 2 preset positions, -15° / +15° tilt |
| Angular Field Of View (max, degree) | 120 |
